True TCIM-530-HA1-A 30" Half Cube Ice Machine Head - 560 lb/24 hr, Air Cooled, 115v/1ph
QUICK SHIP: Typically ships in 1 - 3 Business Days
$4,273.00 /Each
True Refrigeration TCIM-530-HA1-A Description
Designed to produce half-cube ice, the True TCIM-530-HA1-A is an ideal solution for drink stations and fountains. In locations with an ambient temperature of 90 degrees Fahrenheit and incoming water measuring 70 degrees, 500 pounds of ice can be produced. Note that the collection bin is sold separately and is required for operation.
The True TCIM-530-HA1-A True Ice head is controlled via the touchscreen display on the lower left of the front panel. Here, the display shows the status of the machine and any alerts regarding operation. The operator can set production times and amounts or use the one-touch cleaning setting. Monitoring and shutdown procedures can be done remotely, allowing operators to see notifications when away from the machine.
- True Ice series
- Head only
- 560-lb. ice production in 24 hours at 70 degrees ambient air/ 50 degrees incoming water
- 500-lb. ice production in 24 hours at 90 degrees ambient air/ 70 degrees incoming water
- Half-cube ice size: 7⁄16 in. L 1 1⁄8 in. W x 7⁄8 in. H
- Truetech aluminum exterior finish
- TrueGuard antimicrobial components
- Air-cooled condenser
- Environmentally friendly R290 refrigeration
- Easily removable air filter w/ RCU technology
- 4-in. front display
- Diagnostics
- Built-in alarms and push notifications
- Programable ice production
- 1-touch cleaning
- Time of flight ice sensor
- Remote monitoring and shut off
- 30 in. W x 24 in. D x 22 in. H
- 115 V/ 60 Hz/ 1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on True Refrigeration TCIM-530-HA1-A within the 48 contiguous states.
From The Manufacturer
True Ice Series Ice Maker, cube style (half), self-contained, air-cooled condenser, 30"W x 24"D x 22"H, up to 560 lb. production/24 hr, TrueNcapsuL8 insulated & sealed evaporator, TrueGuard built-in Anti Microbial, advanced electronic control with 4.3" touch display, Ice level monitoring, Truetech aluminum exterior finish, R290 Hydrocarbon Refrigerant, UL EPH Classified, cULus
True Refrigeration TCIM-530-HA1-A Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| 24 Hr. Production (lb) | 560 |
| Compressor Type | Air Cooled |
| Depth (in) | 24 |
| Height (in) | 22 |
| Ice Type | Half Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Better |
| Refrigerant | R290 (Hydrocarbon) |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts & Labor |
| Water Inlet (in) | 0.5 |
| Width (in) | 30 |
| Weight | 180.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
True Refrigeration TCIM-530-HA1-A True TCIM-530-HA1-A 30" Half Cube Ice Machine Head - 560 lb/24 hr, Air Cooled, 115v/1ph Current Item |
|||
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $4,273.00 / Each | $3,869.00 / Each | $4,454.00 / Each | $4,046.00 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Ships in 1 Business Day | QUICK SHIP: Typically ships in 1 - 3 Business Days |
| 24 Hr. Production (lb) | 560 | 476 | 516 | 525 |
| Ice Type | Half Cube | Half Cube | Half Cube | Half Cube |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled | Air Cooled |
| Width (in) | 30 | 30 | 30 | 30.25 |
| Rating | Better | Best | Best | Better |
| Voltage | 115 | 115 | 115 | 115 |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts & Labor | Commercial: 3-year Limited Parts & Labor; 5-year Limited Parts & Labor Evaporator; 5-year Limited Compressor & Condenser Parts; Residential: 1-year Parts & Labor | 3-year Parts & Labor; 5-year Evaporator Parts & Labor ; 5-year Compressor Parts; 3-year Compressor Labor | 3-year Parts & Labor; 5-year Evaporator & Compressor Parts |
