True TUC-60-32F-HC~SPEC3 60" W Undercounter Freezer w/ (2) Sections & (2) Doors, 115v

The forced-air refrigeration system on the True TUC-60-32F-HC~SPEC1 Spec Series® undercounter freezer operates at a temperature of -10 degrees Fahrenheit, using a self-contained capillary tube system with R290 hydrocarbon refrigerant to remove heat from the air. Then, airflow is guided through the interior to provide uniform product temperatures. Producing less heat than earlier models, the electronically commutated evaporator and condenser fan motors move more consistent air volumes.

To lengthen the unit's lifespan, the condensing fan motor blows in a reverse direction to eliminate settled dust and debris from the condensing coil's surface. This mechanism helps the coil operate more efficiently by using less energy while cooling products. Though effective, it shouldn't replace carrying out preventive maintenance regularly.

This TUC-60-32F-HC~SPEC1 deep undercounter freezer uses sheet metal interlocks to attach 12-inch-long handles to each door, ensuring permanence. To match the cabinet, doors have white aluminum liner and a stainless steel exterior. Gaskets help create a positive seal around the doors, and they are magnetic to provide tool-free removal and simplify cleaning. Inside, stored product is supported by four wire shelves, each of which includes four chrome-plated shelf clips for adjustments in ¹⁄₂-inch increments. Shelf support pilasters and the cabinet interior are constructed of the same material to match each other.

Product Details

• Part of the Spec Series
• Sheet metal interlock holds a 12-in.-long, recessed handle on each door to ensure permanence
• Matching door and cabinet construction
• Magnetic door gaskets enable tool-free removal
• Doors seal shut and swing within cabinet dimensions
• Each shelf includes 4 chrome-plated shelf clips
• Cabinet interior and shelf support pilasters are the same material
• Operators can adjust shelves in ¹⁄₂-in. increments
• Digital display and electronic temperature control
• Countertop front is flush with door front
• 16-ga. top and 20-ga. doors
• High-density polyurethane insulates doors and cabinet structure
• Interior has coved stainless steel floor and stainless steel liner
• Stainless steel front, sides, top, and back are rust resistant
• Stem castors have a 5-in. diameter
• Front castor set has locks
• 36-in. tall work surface

Forced-air Refrigeration System

• Operating temperature: -10 degrees F
• Self-contained capillary tube system uses R290 hydrocarbon refrigerant
• Airflow moves through the interior for uniform product temperatures
• Electronically commutated motors move more consistent air volumes and produce less heat than earlier models
• Compressor start up causes condensing fan motor to automatically blow in reverse for 20 seconds
• Condensing unit is accessible behind the front grille, which slides out
• Epoxy evaporator reduces corrosion potential
• Time-terminated, time-initiated automatic defrost system

Dimensions & Utilities

• 2 left shelves: 17¹⁄₄ in. L x 28 in. D
• 2 right shelves: 23⁵⁄₈ in. L x 28 in. D
• Overall: 60¹⁄₄ in. W x 35 in. D x 36 in. H
• 5.8 A, ¹⁄₂ HP
• 115 V/60 Hz/1 ph, 7-ft. cord with a NEMA 5-15P plug

From The Manufacturer

SPEC SERIES® Deep Undercounter Freezer, -10°F, side mounted self-contained refrigeration, SPEC Package 3 includes: stainless steel top, (2) heavy-duty stainless steel doors, steel handles, door lock standard, (4) PVC coated adjustable wire shelves, electronic temperature control with digital temperature display, stainless steel sides & back, stainless steel interior, R290 Hydrocarbon refrigerant, 1/2 HP, 115v/60/1-ph, 5.8 amps, NEMA 5-15P, cULus, UL EPH Classified

*Image may not depict product color, inclusions or accessories.

True Refrigeration TUC-60-32F-HC~SPEC3 Specifications

Spec Attribute	Spec Value
Manufacturer	True Refrigeration
Access	Door
Amps	5.8
Application	Undercounter Storage
Base	Casters
Color	Silver
Compressor Location	Side
Cubic Feet	15.9
Depth (in)	35
Door Type	Solid
Height (in)	36
Hertz	60
Interior Construction	Stainless Steel
Sections	2
Special Features	Recessed Handles
Suggested Use	Commercial
Voltage	115
Warranty	7-year Parts & Labor; 7-year Compressor
Width (in)	60.25
Series	Spec Series®
Refrigerant	R290 (Hydrocarbon)
No. of Doors	2
Phase	1
Rating	Best
Product	Undercounter Freezers
Product Type	Commercial Refrigeration
NEMA	5-15P
Hinge Configuration	Left/Right
Weight	415.00
