Hoshizaki IM-544SAK 44" Full Cube Ice Machine Head - 453 lb/24 hr, Air Cooled, 115v/1ph
QUICK SHIP: Typically ships in 1 - 3 Business Days
$6,575.00 /Each
Contact us for details!
Hoshizaki IM-544SAK Description
Producing as much as 453 pounds of ice per 24 hours in ideal conditions, the Hoshizaki IM-544SAK cube ice machine head is suitable to meet the needs of medium-volume establishments. The individual square cube ice melts slowly, making it a good choice for keeping drinks cold without watering them down. This unit operates using R290 refrigerant.
The Hoshizaki IM-544SAK cube ice machine head has a self-contained condenser that won't require any extra coolant lines to install or operate. For streamlined maintenance, this unit has removable panels that enable access to serviceable components. Its EverCheck™ alert system and LED display notify users of settings and facilitate monitoring of performance.
Note: This unit must be paired with an ice maker bin or ice dispenser.
- Cube-style ice
- Cube dimensions: 1 in. W x 1 1⁄4 in. D x 1 in. H
- 453-lb. maximum daily ice production
- 414-lb. AHRI-certified daily ice production
- As many as 3 ice machine heads can be stacked
- Stainless steel finish
- EverCheck digital controls with LED display
- Removable air filters
- Detachable panels provide access to vital components
- Air cooled
- 4,500-BTU heat transfer capacity
- R290 refrigerant
- Ideal incoming air temperature: 45-100 degrees F
- Ideal incoming water temperature: 45-90 degrees F
- Ideal incoming water pressure: 10-113 PSIG
- 44 in. W x 27 5⁄8 in. D x 21 3⁄4 in. H
- 11.5 A, 5.8 kW
- 115 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Hoshizaki IM-544SAK within the 48 contiguous states.
From The Manufacturer
Air-Cooled Modular Square Cube Ice Machine, stackable, produces up to 453 lb of ice per 24 hours at 70°F air / 50°F water, individual square cubes, stainless steel exterior, R290 hydrocarbon refrigerant, EverCheck™ alert system, stackable up to three units high (up to 1,359 lb/24 hr with stacking kits), ambient operating range 45–100°F, water temperature range 45–90°F, water pressure 10–113 PSIG, removable and cleanable air filters, front and right-side service access, requires 115V/60/1 electrical connection, designed for use with compatible ice storage bins
Watch a video about this product
Hoshizaki IM-544SAK Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| 24 Hr. Production (lb) | 453 |
| Also Known As | IM-500SAB |
| Compressor Type | Air Cooled |
| Depth (in) | 27.38 |
| Height (in) | 21.75 |
| Ice Type | Full Cube |
| Phase | 1 |
| Product | Ice Machine Heads |
| Product Type | Ice Makers & Bins |
| Rating | Best |
| Refrigerant | R290 (Hydrocarbon) |
| Suggested Use | Commercial |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Compressor & Condenser Parts |
| Water Inlet (in) | 0.5 |
| Width (in) | 44 |
| Weight | 196.00 |
Important Prop 65 information for California residents.
- Hoshizaki IM500SAA
Compare to Similar Items
| Attributes |
Hoshizaki IM-544SAK Hoshizaki IM-544SAK 44" Full Cube Ice Machine Head - 453 lb/24 hr, Air Cooled, 115v/1ph Current Item |
||
|---|---|---|---|
| Customer Rating |
|
|
|
| Price | $6,575.00 / Each | $4,910.00 / Each | $4,046.00 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Typically ships in 1 - 3 Business Days | QUICK SHIP: Typically ships in 1 - 3 Business Days |
| 24 Hr. Production (lb) | 453 | 582 | 561 |
| Ice Type | Full Cube | Full Cube | Full Cube |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled |
| Width (in) | 44 | 30 | 30.25 |
| Rating | Best | Best | Better |
| Voltage | 115 | 208/230 | 115 |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) |
| Warranty | 3-year Parts & Labor; 5-year Compressor & Condenser Parts | Commercial: 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor & Condenser Parts; Residential: 1-year Parts & Labor | 3-year Parts & Labor; 5-year Evaporator & Compressor Parts |
