Heated Cabinet, Pass-Thru, 2 Section, 4 SS Doors, 6 Shelves, 56 cu ft
True - Model 598-TG2HPT2S2S
|
True introduces its latest offering designed specifically to meet the needs of consultants.
Photo May Include Optional Accessories!
THIS PRODUCT TYPICALLY SHIPS IN 5 - 10 DAYS
|
Pass-Thru Solid Door Heated Cabinet
4 Door
56 Cubic Feet
|
MODEL TG2HPT2S2S |
STANDARD FEATURES:
- Provides cabinet holding temperature of 80˚F to 180˚F (26.67˚C to 82.22˚C).
- Internal fan provides low velocity, forced-air heat distribution to assure even temperatures throughout the cabinet.
- (2) stainless steel 1000 watt finned tube heating elements per section for uniform generation of electric heat. Cabinet comes with a total of 2000 watts.
- 300 series stainless steel door, front, and bottom. The very finest stainless; higher tensile strength for fewer dents and scratches.
- Anodized aluminum interior cabinet liner. 300 series stainless steel door liner and floor with coved corners.
- Three (3) adjustable, heavy duty chrome plated wire shelves 25"L x 27 3/4"D (635 mm x 705 mm) with 1" (26 mm) standoff. Four (4) chrome plated shelf clips to be included per shelf.
- Entire cabinet structure and solid doors are foamed-in-place using high density, CFC free, polyurethane insulation.
- Positive seal self-closing doors with 120 degrees stay open feature. Lifetime guaranteed door hinges and recessed door handles.
Features, Options & Specifications Subject to Change Without Notice. |
|
|
OPTIONAL ACCESSORIES:
Up-charge and lead times may apply. |
KIT OPTIONS:
Up-charge and lead times may apply. |
- 4" (102 mm) diameter swivel castors.
- Seismic/flanged legs.
- All stainless steel legs.
- Stainless steel (electro polished) shelves.
- Chrome shelves.
- Universal pan slides.
- #1 pan slides.
- #2 rod style pan slides.
- Curb mountable units.
- Export units - consult factory.
- Prison package options - consult factory.
- Metal door handle.
- Remote cabinets (condensing units supplied by others), consult factory technical service department for BTU information.
|
- Kit #1: Nine sets of #1 type tray slides, bottom support of one 18" x 26" (456 mm x 661 mm) pan or two 14" x 18" (356 mm x 456 mm) pans.
- Kit #2: One set half-section #2 steel rod tray slides, rim support of one 18" x 26" (456 mm x 661 mm) pan.
- Kit #3: Six sets of universal type tray slides, bottom support of one 18"x 26"(456 mm x 661 mm) pan, two 14"x18" (356 mm x 456 mm) pans or two 12" x 20" (305 mm x 508 mm) pans.
- Kit #4: Three chrome shelves 25"L x 27 3/4"D (635 mm x 705 mm) with 1" (26 mm) standoff and chrome plated shelf supports.
|
|
| |
 |
|
CLICK IMAGE FOR LARGER VIEW
Specification images currently unavailable
|
|
ROUGH - IN DATA |
This Product is recommended for commercial purposes only. |
|
Specifications subject to change without notice
Chart dimensions rounded up to the nearest 1/8"
| Model |
Doors |
Capacity
(Cu. Ft.) |
Dimensions
(Inches) |
Watts |
Volts |
Amps |
NEMA
Config. |
Cord
Length
(total feet)
|
Crated
Weight
|
| L |
D |
H * |
| TG2HPT2S2S |
2 front/2 rear |
56 |
51 3/8 |
37 1/4 |
78 1/4 |
4000 |
115/208-240/1 |
|
|
9 |
600 |
|
* Height does not include 6" for leg
height ( castors available on single section models only). Does not
include 1" for system mechanical components
Requires 115/208 -240/60 Hz, single phase, 3 pole, 4 wire circuit.
Note: TG2HPT-2S-2S requires hard wiring. |
|
|
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only) |
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE |
|
Model |
Elevation |
Right |
Plan |
3D |
| TG2HPT2S2S |
|
|
|
|
|
| |
|
|
|
View Installation Manuals for True Refrigeration Equipment
Product Specifications
- Product Spec Sheet
- Crated Weight: 600.00 lbs.
- Category: Pass Thru/Specialty Heated Cab
- Construction: Aluminum
- Doors: Full Solid/ Full Solid
- Size: Full Height (69" +)
- Slide Type: Adjustable
- Type: Insulated
- Manufacturer: True
- Also Known As: TG2HPT-2S-2S, TRUE TG2HPT-2S-2S, TRUTG2HPT2S2S, 890TG2HPT2S2S, TG2HPT2S2S
