True STG1RPT-2HG-1G-HC 27 1/2" One Section Pass Thru Refrigerator, (3) Right Hinge Glass Doors, 115v
$8,841.16 /Each
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
True Refrigeration STG1RPT-2HG-1G-HC Description
Since it has a top-mounted refrigeration system, the True STG1RPT-2HG-1G-HC pass-thru refrigerator's evaporator is kept away from the food zone and debris on the floor. Its walls are foamed with polyurethane insulation for structure and temperature retention, and it is constructed of stainless steel and aluminum to resist corrosion and dents. Inside, three PVC-coated wire shelves hold product. There are 5-inch-diameter castors that provide movement.
This unit has a self-contained capillary tube system that holds and controls the flow of R290 hydrocarbon refrigerant. Its condenser and evaporator fan motors are electronically commutated to circulate air efficiently without producing much heat or using much energy. This unit holds temperatures in a range from 33 to 38 degrees Fahrenheit, and the user can set the temperature with electronic controls. Its evaporator coils are coated with epoxy to resist corrosion.
To keep the condenser coil clean and subsequently optimize system performance, the compressor’s fan motor reverses for 20 seconds when it starts up to blow away built-up dust, dirt, and debris. When used alongside regular preventive system maintenance, this function reduces energy consumption, keeps temperatures cool and consistent, and lengthens the unit’s lifespan.
With its pass-thru design, this True STG1RPT-2HG-1G-HC one-section refrigerator's front and back can be accessed at the same time. It has three low-e, double-pane glass doors with locks to prevent theft. Metal handles provide a comfortable grip when opening and magnetic gaskets snap into the frame to prevent cold air leaks. The doors can stay open 120 degrees to facilitate loading and unloading. Additionally, the doors close on their own to conserve energy.
- Stainless steel exterior door with matching aluminum exterior sides
- Aluminum interior back and side walls and stainless steel interior ceiling and floor
- 3 PVC-coated wire shelves support product
- Insulated with polyurethane foam to retain temperatures
- 5-in.-dia. castors provide movement
- 3 doors are made of low-e, double-pane glass
- Pass-thru design offers front and back access at the same time
- Door locks prevent theft
- Metal handles facilitate opening
- Doors self-close but stay open past 120 degrees
- 4 cam lift hinges per section secure doors to cabinet
- Magnetic gaskets have a 1-piece construction and create an airtight seal
- LED lighting illuminates the interior
- Temperature is displayed externally in Fahrenheit or Celsius
- Temperature holding range: 33-38 degrees F
- Capillary tube system regulates the flow of R290 hydrocarbon refrigerant
- Electronically commutated condenser and evaporator fan motors move a consistent volume of air
- Self-cleaning, 20-second fan reversal function removes dust and debris from condenser coil
- Top mounted to keep dirt and debris out
- Electronic controls enable user to set temperature
- Epoxy-coated evaporator resists corrosion
- 27 1⁄2 in. W x 39 1⁄8 in. D x 84 1⁄8 in. H
- 3.8 A, 1⁄4 HP
- 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug
*Image may not depict product color, inclusions or accessories.
*Free shipping on True Refrigeration STG1RPT-2HG-1G-HC within the 48 contiguous states.
From The Manufacturer
SPEC SERIES® Refrigerator, pass-thru, one-section, (2) glass half doors front & (1) glass door rear with locks, cam-lift hinges, digital temperature control, (3) gray shelves, LED interior lights, stainless steel front, aluminum sides, aluminum interior, 5" castors, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1-ph, 3.8 amps, NEMA 5-15P, cULus, UL EPH Classified
True Refrigeration STG1RPT-2HG-1G-HC Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | True Refrigeration |
| Additional Info | Contact Customer Service for Additional Information |
| Amps | 3.8 |
| Color | Silver |
| Compressor Location | Top |
| Depth (in) | 36.13 |
| Door Type | Glass |
| Doors | Half |
| Evaporator Type | Capillary Tube |
| Height (in) | 77.75 |
| Hertz | 60 |
| Hinge Configuration | Right |
| Interior Material | Aluminum |
| Kitchen Innovations Awards | 2015 |
| NEMA | 5-15P |
| No. of Doors | 3 |
| Number of Shelves | 3 |
| Phase | 1 |
| Product | Reach-In Refrigerators |
| Product Type | Commercial Refrigeration |
| Rating | Spec |
| Refrigerant | R290 (Hydrocarbon) |
| Sections | 1 |
| Series | Spec Series® |
| Special Features | Casters Included - Uninstalled |
| Supports | Casters |
| Thermometer Type | Digital |
| Type | Pass Thru |
| Voltage | 115 |
| Warranty | 7-year Parts & Labor; 7-year Compressor |
| Width (in) | 27.5 |
| Weight | 430.00 |
WARNING: Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
True Refrigeration STG1RPT-2HG-1G-HC True STG1RPT-2HG-1G-HC 27 1/2" One Section Pass Thru Refrigerator, (3) Right Hinge Glass Doors, 115v Current Item |
True Refrigeration STR1RPT-2HG-1G-HC True STR1RPT-2HG-1G-HC 27 1/2" One Section Pass Thru Refrigerator, (3) Right Hinge Glass Doors, 115v |
True Refrigeration STA1RPT-2HG-1G-HC True STA1RPT-2HG-1G-HC 27 1/2" One Section Pass Thru Refrigerator, (3) Right Hinge Glass Doors, 115v |
|---|---|---|---|
| Customer Rating |
|
|
|
| Price | $8,841.16 / Each | $10,819.36 / Each | $10,062.66 / Each |
| Shipping | Free Shipping | Free Shipping | Free Shipping |
| Rating | Spec | Spec | Spec |
| Width (in) | 27.5 | 27.5 | 27.5 |
| Doors | Half | Half | Half |
| No. of Doors | 3 | 3 | 3 |
| Door Type | Glass | Glass | Glass |
| Type | Pass Thru | Pass Thru | Pass Thru |
| Sections | 1 | 1 | 1 |
| Compressor Location | Top | Top | Top |
| Depth (in) | 36.13 | 36.13 | 36.13 |
| Hinge Configuration | Right | Right | Right |
| Refrigerant | R290 (Hydrocarbon) | R290 (Hydrocarbon) | R290 (Hydrocarbon) |
| Special Features | Casters Included - Uninstalled | Casters Included - Uninstalled | Casters Included - Uninstalled |
| Height (in) | 77.75 | 77.75 | 77.75 |
| Series | Spec Series® | Spec Series® | Spec Series® |
| Warranty | 7-year Parts & Labor; 7-year Compressor | 7-year Parts & Labor; 7-year Compressor | 7-year Parts & Labor; 7-year Compressor |
