Countertop Refrigerated Merchandiser, Glass Door, 2 Shelves, 5 cu ft

GDM Series - Glass Door Merchandisers

TRUE is the world's largest manufacturer of glass door merchandisers.

Model GDM-5

True Glass Door Reach-In Counter Top Cooler, 5 Cubic Feet

This product typically ships in 5 - 10 days.

Features

Standard

The world's #1 manufacturer of glass door merchandisers.

True®'s commitment to using the highest quality materials and oversized refrigeration systems provides the user with colder product temperatures, and lower utility costs in an attractive merchandiser that brilliantly displays packaged food and beverages.

Designed for convenient access, fast service, and attractive display.

Oversized, factory balanced, refrigeration system holds 33° F to 38° F (.5° C to 3.3° C).

Exterior - non-peel or chip white laminated vinyl; durable and permanent.

Interior - attractive, NSF approved, white aluminum interior liner with 300 series stainless steel floor.

Self closing doors. Positive seal, torsion type closure system.

Low-E, double pane thermal glass door assembly. The latest in energy efficient technology.

Entire cabinet structure is foamed-in-place using high density, CFC free, polyurethane insulation.

Safety shielded fluorescent interior lighting for longer, brighter, shadow-free illumination.

Optional Features / Accessories, Up-charge and lead times may apply

230-240V / 50 Hz.

Black exterior.

Rosewood exterior.

Stainless steel exterior.

Red wine thermostat.

Chocolate thermostat.

White wine thermostat.

Barrel locks.

Additional shelves.

1-1/4" (32 mm) pricing strips.

Remote cabinets (condensing unit supplied by others), consult factory technical service department for BTU information.

ENERGY EFFICIENCY / COMPLIANCE

• NSF-7 compliant for pre-packaged and bottled product.
• Evaporator is epoxy coated to eliminate the potential of corrosion.
• This product is certified to the California Energy Commission by the manufacturer as meeting currently applicable efficiency standards. This product either meets federal efficiency standards or, where there are no federal efficiency standards, meets California Energy Commission efficiency standards.

REFRIGERATION SYSTEM

• Factory engineered, self-contained, capillary tube system using environmentally friendly (CFC free) 134A refrigerant.
• Extra large evaporator coil balanced with higher horsepower compressor and large condenser; maintains cabinet temperatures of 33° F to 38° F (.5° C to 3.3° C).
• Sealed, cast iron, self-lubricating evaporator fan motors and larger fan blade gives True merchandisers a superior low velocity, high volume airflow design. This unique design insures faster temperature pull down of warm product, colder holding temperatures and faster recovery in high use situations.

CABINET CONSTRUCTION

• Exterior - non-peel or chip white laminated vinyl; durable and permanent.
• Interior - attractive, NSF approved, white aluminum liner. 300 series stainless floor.
• Insulation - entire cabinet structure and solid doors are foamed-in-place using high density, CFC free, polyurethane insulation.
• Cabinet bottom fitted with leg levelers.
• Illuminated exterior sign panel. Variety of sign options available.

DOORS

• Low-E, double pane thermal glass door assembly with extruded aluminum frame. The latest in energy efficient technology.
• Self closing door. Positive seal, torsion type closure system.
• Door fitted with 15" (381 mm) extruded aluminum handle.
• Magnetic door gasket of one piece construction, removable without tools for ease of cleaning.

SHELVING

• Two (2) adjustable, heavy duty PVC coated wire shelves 19-11/16" L x 18" D (501 mm x 458 mm). Four (4) chrome plated shelf clips included per shelf.
• Shelf support pilasters made of same material as cabinet interior; shelves are adjustable on 1/2" (13 mm) increments.

LIGHTING

• Safety shielded fluorescent interior lighting. Cabinet lighting utilizes electronic ballast and T-8 bulbs for brighter illumination, longer bulb life and increased energy efficiency.

ELECTRICAL CHARACTERISTICS

• Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase - 15 amp dedicated outlet. Cord and plug set included.
