Southbend ETP-10E-SB (10) Pan Convection Steamer - Cabinet, 208v/3ph
$31,111.00 /Each
Call for details!
Southbend ETP-10E-SB Description
The Southbend ETP-10E-SB Eco-Tech™ Plus electric steamer has two full-size compartments, each of which has a generator that stays in ready mode for instant steaming when business picks up. With access ports for delimer and descaler, the generators are mounted at the rear of the compartments. This unit has automatic water level control, and its preheat thermostat is set at 190 degrees Fahrenheit.
This Southbend ETP-10E-SB floor model steamer can hold five 12-inch by 20-inch by 2 1⁄2-inch steam table pans per compartment, and because the interior liners are made of 316 stainless steel, they are highly resistant to corrosion. In the compartments, the right, left, and rear panels can be removed and cleaned thoroughly. For collecting condensate and automatically sending it to the tempering tank, the bottom compartment has a drip trough at the front. Doors on this steamer are made of stainless steel, fully insulated, and have silicone rubber gaskets that prevent steam from leaking out. When one of the doors is opened, the steam power is shut off for employee safety.
- Holds (10) 12-in. x 20-in. x 2 1⁄2-in. pans
- Stainless steel pan support racks
- 316 stainless steel interior liners are highly resistant to corrosion
- Compartment panels on the left, right, and rear are removable
- Front edge of the bottom steaming cavity catches condensate in a drip trough, where it automatically drains to a tempering tank
- 1 steam generator for each compartment
- Generators stay in ready mode for quick response times
- Chambers for the generators are mounted at the back of the steaming cavities
- Delimer and descaler access ports on generators
- Automatic water level control
- Low-water cut-off switch
- Preheat thermostat to 190 degrees F
- High-limit thermostat
- Separate controls for each compartment
- Mode selector enables cavities to be used as holding cabinets
- 60-min. timers
- 316 stainless steel doors are fully insulated and have silicone rubber gaskets that seal in heat
- Door interlock switches shut off power for steaming when a door is opened
- 6-in. adjustable, stainless steel legs
- 24 in. W x 33 in. D x 63 1⁄4 in. H
- 55.5 A, 20 kW
- 208 V/60 Hz/3 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend ETP-10E-SB within the 48 contiguous states.
From The Manufacturer
ECO-TECH™ PLUS Convection Steamer, floor model, electric, (2) compartment, (5) 12" x 20" x 2-1/2" pan capacity per compartment, atmospheric steamer, self contained water filter, automatic water fill, individually controlled by power switch, 60 minute timer, (4) flanged feet, stainless steel interior & exterior, ENERGY STAR®
Southbend ETP-10E-SB Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Also Known As | Market Forge ETP-10E |
| Application | High Volume |
| Base | Cabinet |
| Controls | Manual |
| Depth (in) | 33 |
| Heat | Electric |
| Height (in) | 63.3 |
| Hertz | 60 |
| kW | 20 |
| No. of Compartments | 2 |
| Pan Capacity | 10 or More Pans |
| Pan Type | Full Size Steam Pans |
| Phase | 3 |
| Product | Steamers |
| Product Type | Cooking Equipment |
| Series | Eco-Tech™ Plus |
| Steam Generator | Boiler-Based |
| Steamer Type | Convection |
| Voltage | 208 |
| Warranty | 1-year Limited Parts & Labor |
| Water Source | Plumbed |
| Width (in) | 24 |
| Weight | 425.00 |
