Wells HRCP-7200 Drop-In Hot & Cold Food Well w/ (2) Full Size Pan Capacity, 208-240v
$15,043.00 /Each
Call for details!
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Wells HRCP-7200 Description
The Wells HRCP-7200 drop-in food well supports hot and cold operation, which is managed with the easy-access control panel. When switched to the heated Bain Marie pan, this unit uses water and an electric immersion system to transfer heat. For safe regulation, this unit functions with a solenoid value and water sensor. The self-contained refrigeration system works to produce cool air with 134A refrigerant when cold operation is needed. For simple cleaning and servicing, the condensing unit is removable and located below the cold pan.
Constructed of corrosion-resistant steel with a one-piece stainless steel top flange, the Wells HRCP-7200 hot/cold food well’s exterior supports heavy-duty use, while the interior features coved corners to streamline cleaning. Foamed-in-place insulation sits between the unit’s metal paneling for added strength and temperature retention, and a drain is included to eliminate excess water. Equipped with two wells, this unit can hold (2) 12-inch by 20-inch pans, and adaptor bars are provided for use with the food pans.
- Holds (2) 12-in. x 20-in. food pans
- Corrosion-resistant steel exterior
- One-piece stainless steel top flange
- 3-in. recessed top edge
- Interior coved corners
- Foamed-in-place insulation
- 1-in. drain
- Provided with adaptor bars
- Control panel attached to 24-in.-long conduit
- For wet operation only
- Automatic water fill
- Water sensor
- Solenoid value
- Efficient electric immersion
- Self-contained
- 134A refrigerant
- Air cooled
- Features sight glass, easy-service valves, dryer/filter, and receiver
- Removable condensing unit located below the cold pan
- Interior: 27 1⁄2 in. W x 21 7⁄8 in. D
- Overall: 32 3⁄4 in. W x 27 1⁄8 in. D x 25 1⁄8 in. H
- 9/10.4 A, 1.9/2.5 kW
- 208/240 V/60 Hz/1 ph (convertible to 3 ph)
- 4.9 A, 1⁄4 HP
- 115 V/60 Hz/1 ph (convertible to 3 ph)
*Image may not depict product color, inclusions or accessories.
*Free shipping on Wells HRCP-7200 within the 48 contiguous states.
From The Manufacturer
Hot/Cold Drop In Unit, 2-pan size, single tank with switch for hot or cold operation with self-contained refrig., automatic water fill, includes (2) pan dividers, R134a, (COLD) 1/4 HP, 115v/60/1-ph, 4.9 amps, (HOT) 208/240v/60/1-ph, 9.0-10.4 amps, direct, NSF, cULus
Wells HRCP-7200 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Wells |
| Accommodates | Full Size Pans |
| Height (in) | 25.13 |
| Length (in) | 32.75 |
| Operation | Convertible |
| Operation | Dry |
| Operation | Wet |
| Pan Capacity | 2 |
| Phase | 1 |
| Phase | 3 |
| Product | Food Wells |
| Product Type | Food Bars & Buffets |
| Type | Drop In |
| Voltage | 208/240 |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 32.75 |
| Weight | 231.00 |
