Southbend DCX-10S-10 (10) Pan / (1) Kettle Convection Steamer - Cabinet, Direct Steam
$43,958.80 /Each
Call for details!
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Southbend DCX-10S-10 Description
The Southbend DCX-10S-10 convection steamer and kettle combination is designed for high-volume cooking applications, featuring two independent steam compartments and a 10-gallon kettle. Each steamer compartment can hold up to five 12-inch by 20-inch pans, while the integrated kettle provides versatile cooking options. This unit operates on direct steam and is built with a 48-inch cabinet base for added stability and storage. It includes an automatic blowdown system and a 60-minute timer per compartment for precise cooking control.
Constructed of stainless steel inside and out, the Southbend DCX-10S-10 steamer is equipped with a deck-mounted faucet valve with a swing nozzle and an integral sink, simplifying kettle filling and cleaning. The unit features an insulated, fully welded cooking chamber, removable stainless steel pan supports, and a positive lock-and-seal mechanism for reliable operation. With adjustable flanged feet, this convection steamer and kettle combination provides stability for commercial kitchen environments.
- Steamer/kettle combination
- Direct steam operation
- 2 independent steamer compartments
- (1) 10-gal. kettle
- Holds up to (5) 12-in. x 20-in. pans per compartment
- 60-minute timer per compartment
- Deck-mounted faucet valve with swing nozzle
- Integral sink for easy operation
- Stainless steel construction inside and out
- 6-in. legs with adjustable flanged feet
- 48 in. W x 33 in. D x 68 1⁄2 in. H
- 120 V/60 Hz/1 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Southbend DCX-10S-10 within the 48 contiguous states.
From The Manufacturer
Convection Steamer/Kettle, direct steam, (2) compartment, (1) 10 gallon kettle, (5) 12" x 20" pan capacity per compartment, 48" cabinet base, automatic blowdown, 60 minute timer per compartment, deck mount faucet valve, swing nozzle & intregal sink, CSD-1 code package, stainless steel interior & exterior, 6" legs, adjustable bullet feet front, adjustable flanged feet rear, CSA, NSF
Southbend DCX-10S-10 Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Also Known As | Crown DCX-10-10 |
| Application | High Volume |
| Base | Cabinet |
| Controls | Manual |
| Depth (in) | 33 |
| Heat | Direct Steam |
| Height (in) | 68.5 |
| Hertz | 60 |
| Kettle Capacity | 10 gal |
| No. of Compartments | 2 |
| No. of Kettles | 1 |
| Pan Capacity | 10 or More Pans |
| Pan Type | Full Size Steam Pans |
| Phase | 1 |
| Product | Steamers |
| Product Type | Cooking Equipment |
| Steam Generator | Boiler-Based |
| Steamer Type | Convection |
| Voltage | 120 |
| Warranty | 1-year Limited Parts & Labor |
| Water Source | Plumbed |
| Width (in) | 48 |
| Weight | 920.00 |
