Evo 10-0340-40E 48" Electric Griddle w/ Digital Controls - 3/4" Steel Plate, 208v/3ph
Retail Price: $18,500.00
$14,430.00 /Each
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Similar Products in Stock Now
Evo 10-0340-40E Description
The Evo Elevation 10-0340-40E electric griddle offers edge-to-edge cooking with variable temperatures ranging from 200 to 650 degrees Fahrenheit. Designed with Smart Heat Technology™, it maximizes heat recovery while cooking. A resistive touch screen display provides user-selectable preset temperatures, and the unit includes two programmable presets for quick adjustments. Its steel griddle plate measures 40 inches wide by 281⁄2 inches deep with a thickness of 3⁄4 inch, ensuring even heat distribution.
The Evo 10-0340-40E griddle features an automatic idle mode to conserve energy during low-use periods. Adjustable 4-inch legs enable simple cleaning beneath the unit. It requires a Type 1 commercial exhaust hood and a minimum clearance of 2 inches on the sides and back for ventilation.
Product Details
- Evo Elevation series
- Resistive touch screen with 2 programmable presets
- Edge-to-edge cooking with 200–650 degrees Fahrenheit temperature range
- Smart Heat Technology enhances heat recovery
- Automatic idle feature conserves energy
- Adjustable 4-in. legs
- Requires Type 1 commercial exhaust hood
Dimensions & Utilities
- Overall: 48 in. W x 32 in. D x 151/2 in. H
- Grilling surface: 40 in. W x 281⁄2 in. D x 3/4 in. H
- 45 A, 12.1 kW
- 208 V/60 Hz/3 ph
*Free shipping on Evo 10-0340-40E within the 48 contiguous states.
From The Manufacturer
Evo® Elevation™ 40E High Temp Griddle, electric, countertop, 40” x 28.5” x .75” grilling surface, 650°F max temperature, (2) programmable presets, touch screen display, includes: professional grill surface cleaning kit with handle, griddle cleaning pad and screen, 2 stainless steel spatulas, 1 stainless steel grill scraper, adjustable 4" legs, 208v/60/3-ph, 12.1 kW, 45 amps, cULus, UL EPH Classified, Made in USA
*Image may not depict product color, inclusions or accessories.
Evo 10-0340-40E Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Evo |
| Application | Medium Duty |
| Cooking Area Depth (in) | 28.5 |
| Cooking Area Width (in) | 40 |
| Controls | Thermostatic |
| Heat | Electric |
| kW | 12.1 |
| Hertz | 60 |
| Plate Material | Steel |
| Plate Thickness (in) | 3/4 |
| Phase | 3 |
| Rating | Better |
| Series | Evo® Elevation™ |
| Product Type | Countertop Cooking Equipment |
| Product | Griddles |
| Voltage | 208 |
| Warranty | 1-year Limited |
| Width (in) | 48 |
| Weight | 575.00 |
