Wells HRCP-7500 Drop-In Hot & Cold Food Well w/ (5) Full Size Pan Capacity, 208-240v/1ph/3ph

Write a Review!KaTom #: 439-HRCP7500 • MPN: HRCP-7500
  • 439-HRCP7500 Primary Thumbnail Image
Free Shipping Item

$20,260.00 /Each

Web price, call us!

  • Protect Your Product
  • Coverage starting at $125.25
  • Edit Remove

Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.

Wells HRCP-7500 Description

Staff can flip the Wells HRCP-7500 dual-temperature well's switch to initiate cold or hot operation. When appetizers, entrees, or desserts need to be held at cool temperatures, its air-cooled, self-contained refrigeration system uses R404A refrigerant to produce desired temperatures; its large compressor expedites cooling. To ease maintenance, this system includes a sight glass, service valves, a dryer/filter, a receiver, and a removable condensing unit. The wet heating system automatically fills the pan with water, while an electric immersion heating system warms water to the temperature operators set on the positive-off thermostat controls. To eliminate manual refilling, its water sensor and solenoid value maintain high water levels.

The Wells HRCP-7500 hot and cold unit can be dropped in a 7234-inch-wide by 2578-inch-deep cutout for a seamless appearance on food bars. For convenient temperature adjustment and monitoring, the temperature and function control panel is attached to a 24-inch-long flexible conduit that enables installation in a convenient location. Made of stainless steel, this 74-inch-wide by 2718-inch-deep by 2518-inch-tall unit resists rust, corrosion, and wear, ensuring lasting durability through front- or back-of-house use. To maintain generated temperatures, it's foamed in place with CFC-free insulation. As many as five 12-inch by 20-inch pans can be displayed on this unit, which features adapter bars to enhance organization. For simple cleanup after use, residue can be removed through the 1-inch center drain.

Product Details

  • Accommodates (5) 12-in. x 20-in. food pans
  • Drop-in configuration
  • 18-ga. stainless steel top flange and coved-corner interior
  • Heavy-gauge stainless steel exterior
  • Ledge is recessed 3 in.
  • Foamed-in-place CFC-free insulation
  • 1-in. center drain
  • Can be dropped in a 7234-in.-wide x 2578-in.-deep cutout
  • Temperature and function control panel attached to 24-in.-long flexible conduit for remote installation
  • Single switch initiates hot or cold operation
  • Includes adapter bars

Refrigeration System

  • Air cooled and self-contained
  • Wrapped-coil construction
  • R404A refrigerant
  • Large, quick-cooling compressor
  • Sight glass, easy-service valves, dryer/filter, and receiver
  • Condensing unit can be removed

Heating System

  • Wet operation only
  • Automatic water fill
  • High-limit protection
  • Water sensor and solenoid value
  • Electric immersion heating system
  • Positive-off thermostat

Dimensions

  • Interior: 6834 in. W x 2178 in. D
  • Overall: 74 in. W x 2718 in. D x 2518 in. H

Refrigeration Utilities

  • 15.2 A, 34 HP
  • 115 V/60 Hz/1 ph

Heating Utilities

  • 28.9/33.3 A, 6.0/8.0 kW
  • 208/240 V/60 Hz/1 ph

Product Features

Wells HRCP7500 Features

*Free shipping on Wells HRCP-7500 within the 48 contiguous states.

From The Manufacturer

Hot/Cold Drop In Unit, 5-pan size, single tank with switch for hot or cold operation with self-contained refrig., automatic water fill, includes (2) pan dividers, R404a, (COLD) 3/4 HP, 115v/60/1-ph, 15.2 amps, (HOT) 208/240v/60/1-ph, 28.9-33.3 amps, direct, NSF, cULus

*Image may not depict product color, inclusions or accessories.

Warranty Icon
1-year Limited Parts & Labor

Wells HRCP-7500 Specifications

Certifications
This product is made in the USA.
This product has been certified by the NSF (National Safety Foundation), as meeting international...
UL evaluated with respect to specific properties, a limited range of hazards or suitability for u...
Residential Users: The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.
