Manitowoc Ice IY-0524A 22" Indigo™ Half Cube Ice Machine Head - 485-lb/24-hr, Air Cooled, 115v

Image may not depict product color, inclusions or accessories.

KaTom #: 399-IY0524A161 • MPN: IY-0524A 161

Ships Free

Typically ships within 1 - 3 business days

(0 reviews)Write a Review
Price: $2,867.00
Login or call us for more info!

Image may not depict product color, inclusions or accessories.

Manitowoc Ice IY-0524A Description

Manitowoc Ice

The Manitowoc Ice IY-0524A half-cube ice machine is part of the Indigo™ Series, which is the replacement to the S Series. This air-cooled ice maker uses a new acoustical ice sensing probe to detect the thickness of the ice before dropping into the ice bin and is controlled by an EasyRead display that is illuminated. For thorough cleaning, the foodzone has removable internal components and certain components are made of AlphaSan® antimicrobial to inhibit microbial growth.

Product Details

  • Replaces SY-0424A
  • Half-dice style ice - 3/8-in. W x 1-1/8 in. D x 7/8-in. H
  • Air-cooled
  • 485-lbs. of ice produced daily
  • EasyRead display is illuminated with a blue backlight and communicates the operation status, cleaning schedules, and asset information
  • 7 days’ worth of data is collected for diagnostic feedback and 24-hr. preventative maintenance
  • Ice production can be set based on time of day, ice volume, and bin level (with bin level control)
  • Acoustical ice sensing probe uses sound to detect the thickness of the ice before dispensing it into the bin
  • Removable internal components (water-trough, distribution tube, curtain, and sensing probes) make cleaning the foodzone easy and is sealed for more efficient cooling
  • To fight microbial growth, the distribution tube, evaporator, water tray, sensing probe, and drain tube are built with AlphaSan®
  • DuraTech™ stainless steel construction and clear coat resist fingerprints and corrosion
  • 115 V/60 Hz/1-ph, 14.4 A, plug and cord are not included
  • Overall Dimensions: 22-in. W x 24-1/2 in. D x 21-1/2 in. H
  • CE and cULus Listed; AHRI, ISO 9001:2008, NSF, and ENERGY STAR Certified; California Low Lead Qualified
  • Note: a bin is required for operation and plug and cord are not included

Durable Exterior, Smart Interior

  • DuraTech™ clear coat has superior corrosion and fingerprint resistance and is on top of a stainless finish for a professional and clean appearance
  • Onboard processing collects information on the production times, asset information, and any mechanical failures to give you advice on how to maintain your ice maker. This information can also be accessed during maintenance for shorter down times and easier identification of problems
  • Acoustical ice sensing probe is an improvement over the water conductivity probe because it will not fail if it becomes dirty. It uses sound to detect the thickness of the entire sheet of ice before dispensing it into the bin

Indigo™ Series Ice Maker, cube-style, air-cooled, self-contained condenser, 22"W x 24-1/2"D x 21-1/2"H, production capacity up to 485 lb/24 hours at 70°/50° (360 lb AHRI certified at 90°/70°), DuraTech™ exterior, half-dice size cubes (not stackable), NSF, cULus, 115v/60/1ph

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Manitowoc Ice IY-0524A Specifications

PDF Spec Sheet
Manufacturer Manitowoc Ice
24 Hr. Production (lbs) 485 lbs
Also Known As 399-SY0424A,399-IY0594N161, SY-0424A, IY-0594N, SY0424A, QY0424A, JY0424A, BY0424A
Compressor Type Air Cooled
Depth (in) 25
Height (in) 22
Ice Type Half Cube
Specialty Options Digital Controls
Width (in) 22
Warranty 3-yr. Parts & Labor, Add'l 2 yrs. Evaporator; Add'l 2 yrs. Parts Compressor
Production Range 300-899 lb
Hertz 60
Voltage 115
Phase 1
Weight 145.00
Manitowoc Ice IY-0524A Certifications
  • UL
  • NSF
