Manitowoc Ice IY-0454A 30" Indigo™ Cube Ice Machine Head - 450-lb/24-hr, Air Cooled, 115v

KaTom #: 399-IY0454A161 • MPN: IY-0454A 161 (115/60/1)
free-shipping

Typically ships within 1 - 3 business days

(1 review)Write a Review
Retail Price: $2,868.00

Manitowoc Ice IY-0454A Description

The Manitowoc IY-0454A 161 Indigo™ Series cube ice machine head generates up to 450 pounds of half dice-style ice in 24 hours. An ice-sensing probe makes sure the ice is thick enough to dispense, even when the water is high in dissolved solids. The EasyRead illuminated display provides simple control of production levels, shows diagnostic feedback, and indicates when it is time for preventive maintenance. The durable DuraTech™ stainless steel exterior is coated to resist fingerprints, dirt, and damage, while many components have AlphaSan® built in to slow microbial growth. The Manitowoc IY-0454A 161 Indigo™ Series cube ice machine head requires a separately-sold storage bin to hold ice. Ambient temperatures must be between 35 and 110 degrees for proper production.

Product Details

  • Air-cooled for cost-effective operation
  • 450-lb. capacity for high yield applications
  • Ice Cube Dimensions: 38 in. x 118 in. x 78 in.
  • Ice production can be controlled based on time of day or ice volume
  • Operation status, cleaning reminders, and asset information are communicated through the illuminated EasyRead Display
  • Acoustical ice sensing probe ensures that the ice is at the optimal thickness before being dispensed
  • Uses R-404A refrigerant to maintain cool temperatures
  • Unit must be installed in an area that has an ambient temperature range within 35-110 degrees F
  • 115 V/60 Hz/1 ph, 13.2 A, 5400-6300 BTU
  • Overall Dimensions: 30 in. W x 2412 in. D x 2112 in. H
  • California Low Lead qualified; CE and cULus listed; AHRI and NSF certified

Construction

  • AlphaSan® components slow down microbial growth
  • Stainless steel exterior has a DuraTech™ clear coat resists dirt and damage
  • Requires a storage bin that must be purchased separately
  • Hinged front door for easy accessibility
  • Water trough, distribution tube, curtain, and sensing probes are all removable for cleaning

Indigo™ Series Ice Maker, cube-style, air-cooled, self-contained condenser, 30"W x 24-1/2"D x 21-1/2"H, production capacity up to 450 lb/24 hours at 70°/50° (335 lb AHRI certified at 90°/70°), DuraTech™ exterior, half-dice size cubes, NSF, cULus, ENERGY STAR®, 115v/60/1ph

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Manitowoc Ice IY-0454A Specifications

PDF Spec Sheet
Manufacturer Manitowoc Ice
24 Hr. Production (lbs) 450 lbs
Also Known As 399-SY0454A, SY-0454A, QY0454A, JY0454A, BY0454A, GY0404A, EY0404A, CY0404A, AY0404A
Compressor Type Air Cooled
Depth (in) 25
Height (in) 22
Ice Type Half Cube
Specialty Options Antimicrobial System
Specialty Options Digital Controls
Voltage 115/60/1
Width (in) 30
Warranty 3-yr. Parts & Labor, Add'l 2 yrs. Evaporator; Add'l 2 yrs. Parts Compressor
Weight 170.00
Manitowoc Ice IY-0454A Certifications
  • UL
  • NSF
  • Energy Star
