Southbend 4602AA-4GR 60" 2 Burner Gas Range w/ Griddle & (2) Convection Ovens, Natural Gas
$19,197.00 /Each
Web price, call us!
Selected Gas Type: Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Southbend 4602AA-4GR Description
The Southbend 4602AA-4GR NG gas range is heated by natural gas, and a manual gas shut-off valve is located on the front of the unit for safety. There is a 48-inch griddle on the right side of the unit, with two non-clogging burners that have wavy grates sitting above them. A 4-inch, stainless steel front rail acts as a resting place for plates. The front and sides of the unit are made from stainless steel for durability and corrosion resistance.
Two convection ovens are on the bottom of the unit, and they can be used as regular ovens with the flip of a switch. The temperature range on both ovens is 175 to 550 degrees Fahrenheit. Since the doors of the ovens have spring-assisted hinges, opening and closing them is easier. The interior is protected by double-sided, full-porcelain enamel, which is easy to clean and resistant to corrosion. The interior corners are coved to make cleaning debris out easier and to enhance the flow of air to prevent hot and cold spots. The Southbend 4602AA-4GR NG gas range uses a battery-spark to ignite the ovens' burners and a standing pilot for cooktop burners.
Product Details
- Heated by natural gas
- 1 right-sided, 48-in. griddle
- 2 non-clogging burners have wavy grates sitting above
- 4 removable, cast-iron grate tops
- Manual gas shut-off valve located on the front for the entire unit
- Stainless steel front and sides are durable and corrosion resistant
- 4-in. front rail made from stainless steel acts as a resting place for plates
- Standing pilot light ignites the open top burners
- Battery-spark ignited oven burners
- Factory-installed gas regulator
- 221⁄2 in. flue riser with a shelf
- 6-in. adjustable legs
- 198,000 BTU cooktop heat input
- Overall Dimensions: 60.75 in. W x 42.13 in. D x 59.50 in. H
2 Convection Ovens
- 3 racks per oven
- 175-550 degrees F temperature range
- On/off switch controls fans so ovens can be used without convection heat
- Opening and closing doors on the oven is easier with spring-assistance
- Cleaning is easy since the oven cavity is fully coated in porcelain enamel on both sides
- Coved corners help prevent hot and cold spots by improving airflow
- Split phase motor with permanent lubricated ball bearings
- 32,000 BTU heat input per convection oven
- 115 V/60 Hz/1 ph, 1⁄2 HP
*Free shipping on Southbend 4602AA-4GR within the 48 contiguous states.
From The Manufacturer
Ultimate Restaurant Range, NG gas, 60", (2) non-clog burners, wavy grates, (1) 48" griddle right, standing pilot, (2) convection ovens with battery spark ignition, includes (3) racks per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 198,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
Southbend 4602AA-4GR Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Convection Oven |
| BTU / Burner | 33000 |
| Burner Configuration | Standard |
| Burner Style | Wavy Grates |
| Burner Type(s) | Open |
| Controls | Manual |
| Convection Oven BTU/hr | 32000 |
| Convection Oven Dimensions | 26"W x 24"D x 14"H |
| Depth (in) | 43.6 |
| Gas Inlet Size | 0.75 |
| Gas Type | NG |
| Griddle Location | Right |
| Griddle Width (in) | 48 |
| Heat | Gas/Electric |
| Height (in) | 59.5 |
| Hertz | 60 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 2 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 33000 |
| Phase | 1 |
| Plate Thickness (in) | 1 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Convection Oven | 5 |
| Racks per Convection Oven | 3 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 198000 |
| Vent | Backriser w/ hi-shelf |
| Voltage | 115 |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
Important Prop 65 information for California residents.
