Southbend 4601DD-4TR 60" 2 Burner Gas Range w/ Griddle & (2) Standard Ovens, Liquid Propane
$16,013.00 /Each
Web price, call us!
Selected Gas Type: Liquid Propane
Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Southbend 4601DD-4TR Description
For flexibility, the Southbend 4601DD-4TR commercial range has two burners and a 48-inch griddle on top, which is great for kitchens that cook many different products. Positioned to the right of the burners, the griddle has a 1-inch-thick plate that resists warping and evenly distributes heat. Because the plate sides are raised, they contain crumbs and liquids. A front rail on this range holds plates while users finish dishes, and the flue riser directs excess heat to the hood ventilation system above the unit.
Since the Southbend 4601DD-4TR two-burner gas range with griddle has two standard ovens in its base, it can be used for baking and roasting as well. These ovens do not have convection fans, so they do not distribute heat as evenly, though they still work well for finishing dishes. Each oven chamber has one rack and accommodates full-size sheet pans positioned front-to-back or side-to-side.
Product Details
- (2) 24,000-BTU left open burners
- 48-in., 80,000-BTU right griddle
- 1-in.-thick polished steel griddle plate is durable and evenly distributes heat
- Plate sides are raised to contain debris
- Thermostatically controlled griddle
- Front has a 4-in. stainless steel plating rail
- 22.5-in. flue riser has a high shelf for small equipment
- Front and sides are made of stainless steel
- 6-in., adjustable stainless steel legs
- 208,000 total BTU
Product Features
2 Standard Ovens
- Double-sided, porcelain-enameled cavities ease cleaning with their nonstick surface
- 1 rack with a 2-position guide
- Accommodates full-size pans side-to-side and front-to-back
- Counterweight doors are spring assisted for comfortable opening
- Adjustable thermostatic control
- Temperature range: 175-550 degrees F
- Battery spark ignition
- 40,000 BTU per oven
Dimensions & Utilities
- Oven interiors: 26 in. W x 26.5 in. D x 14 in. H
- Overall: 60.75 in. W x 34 in. D x 59.5 in. H
- LP gas powered
- 3⁄4-in. gas connection
*Free shipping on Southbend 4601DD-4TR within the 48 contiguous states.
From The Manufacturer
Ultimate Restaurant Range, LP gas, 60", (2) non-clog burners, standard grates, (1) 48" griddle right, thermostatic controls, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 236,000 BTU, CSA, NSF
*Image may not depict product color, inclusions or accessories.
Southbend 4601DD-4TR Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Southbend |
| Additional Info | Contact Customer Service for altitudes above 2,000 feet |
| Application | Restaurant |
| Base | Standard Oven |
| BTU / Burner | 24000 |
| Burner Configuration | Standard |
| Burner Style | Grates |
| Burner Type(s) | Open |
| Controls | Thermostatic |
| Depth (in) | 34 |
| Gas Inlet Size | 0.75 |
| Gas Type | LP |
| Griddle Location | Right |
| Griddle Width (in) | 48 |
| Heat | Gas |
| Height (in) | 59.5 |
| Installation Type | Freestanding |
| Max Temp | 550 |
| Number of Burners | 2 |
| Number of Ovens | Double |
| Open Burner BTU (ea) | 24000 |
| Plate Thickness (in) | 1 |
| Product | Gas Ranges |
| Product Type | Cooking Equipment |
| Rack Positions per Standard Oven | 2 |
| Racks per Standard Oven | 1 |
| Range Configuration | Burners/Griddle |
| Rating | Better |
| Series | Ultimate |
| Special Features | Spark Ignition |
| Standard Oven BTU/hr | 45000 |
| Standard Oven Dimensions | 26"W x 26.5"D x 14"H |
| Total BTU | 236000 |
| Vent | Backriser w/ hi-shelf |
| Warranty | 1-year Limited Parts & Labor |
| Width (in) | 60 |
| Weight | 1075.00 |
