Southbend 4601DD-3TR 60" 4-Burner Gas Range with Griddle, NG

Image may not depict product color, inclusions or accessories.

KaTom #: 348-4601DD3TRNG • MPN: 4601DD-3TR NG

Ships Free

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Web Price: $9,042.00

Selected Gas Type: Natural Gas

Image may not depict product color, inclusions or accessories.

Southbend 4601DD-3TR Description


Southbend's 4601DD-3TR NG 60 inch restaurant range features a cooktop with a 36 inch, thermostatically-controlled griddle and four burners with cast iron grates. Two standard ovens form the base of this range, each of which contain a 45,000 BTU oven burner and one rack which is adjustable on two settings. Those ovens also accommodate full-size sheet pans both front-to-back and side-to-side.

Product Details

  • (4) 33,000 BTU burners with cast iron burner grates
  • Rear burner grates accommodate stock pots as large as 14-in. diameter
  • Fully-removable drip trays capture grease and crumbs to help keep range clean and sanitary
  • Top burners are lit by a standing pilot light
  • 37-in. working height for operator comfort and convenience
  • 4-in. stainless steel front rail provides a landing place for plates and cookware and also helps protect operators from touching burners
  • For safety and simple servicing, a manual gas shutoff valve is locate at the front of the range
  • A factory-installed gas pressure regulator provides consistent flames and a safe gas pressure
  • 2212 inch high flue rises includes a heavy-duty, all-purpose stainless steel shelf
  • 6-in. adjustable legs allow for level installation on uneven flooring
  • 2212 in. flue riser with heavy duty shelf is included
  • Overall Dimensions: 6034 in. W x 34-in. D x 5912 in. H
  • CE, cCSAus, CSA-Gas, and CSA-Design Listed; NSF Certified

Manually-Controlled Polished Steel Griddles

  • 12 in. thick, polished steel griddle plate
  • Raised sides make griddle easier to use, clean, and maintain
  • Thermostatic controls make for simple and convenient temperature control and maintenance
  • Griddle is located to the left of the range's top burners

Twin Standard Oven Base

  • Powerful 45,000 BTU oven burners for quick heating and excellent temperature recovery
  • Thermostatic controls are easy for users of all skill levels to operate
  • Oven doors are spring-assisted and counterweighted to make them easy to open and close
  • Double-sided, fully-porcelain enameled interior for easy cleaning, corrosion protection, and even heat distribution
  • Coved interior corners make ovens easy to clean and help spread heat evenly
  • Each oven measures 26-in. W x 14-in. H x 2612-in. D
  • Ovens each accommodate full-size sheet pans both front-to-back and side-to-side
  • Includes 1 rack per oven, each adjustable on 2 positions

Ultimate Restaurant Range, NG gas, 60", (4) non-clog burners, standard grates, (1) 36" griddle right, thermostatic controls, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 286,000 BTU, CSA, NSF

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Southbend 4601DD-3TR Specifications

PDF Spec Sheet
Manufacturer Southbend
Application Restaurant
Base Standard Oven
BTU / Burner 33000
Gas Type NG
Heat Gas
Range Configuration Burners
Range Configuration Griddle
Width (in) 60
Warranty Standard 1 Year
Warranty 1 year limited parts and labor
Width (in) Range 50 - 69 in
Weight 1075.00
Southbend 4601DD-3TR Certifications
  • NSF
