Southbend 4601DD-3TL 60" 4-Burner Gas Range with Griddle, LP

KaTom #: 348-4601DD3TLLP • MPN: 4601DD-3TL LP

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Retail Price: $14,843.00
$8,163.65 / Each

Southbend 4601DD-3TL Description

Southbend's 60 inch restaurant range features four non-clog burners and a 36 inch griddle. Two standard ovens form the base of this 4601DD-3TL LP range, each of which are heated with a 40,000 BTU burner and are built with porcelain-coated interiors which create even baking temperatures and make the ovens easy to clean. The burners, griddle, and oven feature thermostatic controls to make operation simple and consistent.

Product Details

  • Non-clog 24,000 BTU top burners
  • Durable cast iron burner grates
  • Top burners are lit by standing pilot flame
  • Cook top is a comfortable 37-in. height
  • 4-in. deep stainless steel front rail provides a landing surface for plating food directly from range top
  • Manual gas cutoff valve is located at the front of the range for operator convenience and safety
  • Includes factory-installed gas regulator for safety and convenience
  • Stainless steel front, sides, and shelf are easy to clean and lend themselves to a long product life
  • Fully-removable drip trays catch crumbs and grease to easily maintain a tidy, sanitary environment
  • Runs on LP gas
  • 2212 in. flue riser included
  • Overall Dimensions: 34-in. W x 34-in. D x 5912 in. H
  • CE, cCSAus, CSA-Design, and CSA-Gas Listed; NSF Certified

Double Standard Oven Base

  • Each oven includes a 40,000 BTU burner
  • 175 to 550 degree F thermostatic controls make oven easy to operate
  • Even-heating, easy-to-clean porcelain-coated oven interiors
  • Coved corners make interior easy to wipe free of debris
  • Oven interior dimensions measure 26-in. W x 2612 in. D x 14-in. H
  • Each oven accommodates full-size pan sheets both front-to-back and side-to-side

36-Inch Griddle With Thermostatic Controls

  • 12-in. thick polished steel griddle plate is made for even heating and reduced hot spots
  • Raised griddle sides contain grease and make for easy cleaning
  • Griddle temperatures are easy to maintain via thermostatic controls
  • Griddle is located to the left of range top burners

Ultimate Restaurant Range, LP gas, 60", (4) non-clog burners, standard grates, (1) 36" griddle left, thermostatic controls, standing pilot, (2) standard ovens with battery spark ignition, includes (1) rack per oven, 22-1/2" flue riser with shelf, stainless steel front, sides, shelf & 6" adjustable legs, 286,000 BTU, CSA, NSF

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Southbend 4601DD-3TL Specifications

PDF Spec Sheet
Manufacturer Southbend
Application Restaurant
Base Standard Oven
BTU / Burner 33000
Gas Type LP
Heat Gas
Range Configuration Burners
Range Configuration Griddle
Width (in) 60"
Warranty Standard 1 Year
Warranty 1 year limited parts and labor
Weight 1075.00
Southbend 4601DD-3TL Certifications
  • NSF
