Vulcan VIR1F Deck-Broiler w/ Infrared Burners, Refrigerated Base, Natural Gas

The Vulcan VIR1F infrared upright broiler has a 25¹⁄₂-inch-wide by 24¹⁄₂-inch-deep cooking grid to broil different foods simultaneously. Made of cold-rolled steel bars, the grid creates grill marks for presentation; its openings also facilitate air circulation around product for even heating. Using natural gas, it's heated by four 25,000-BTU infrared burners, which can be turned on with the pilot ignition system. User can adjust burner output with two infinite heat valves, and the cooking grid can be raised or lowered in five different positions to achieve desired results.

The bottom deck of the Vulcan VIR1F upright broiler is a refrigerator, which can store meats, vegetables, and other ingredients prior to cooking. The unit's front, front top, ledge, base, stub back, and top are made of stainless steel for durability, and it's supported by 6-inch stainless steel legs for stability. Overall, this broiler measures 36 inches wide by 42⁵/₈ inches deep by 77¹/₈ inches high and generates 100,000 BTUs per hour.

Product Details

• Part of the V Series
• Top level has a broiler
• Bottom level is a refrigerated base
• (4) 25,000-BTU burners
• Accessible pilot ignition system
• 2 infinite heat controls for burners
• Spring-balanced, cold-rolled steel cooking grid with 5 positions
• Front, top front ledge, and sides composed of stainless steel
• 1¹⁄₄-in.-diameter front gas manifold
• Full-width, floating stainless steel drip pan
• 6-in. adjustable stainless steel legs
• Rear clearance: 6 in.
• 100,000 BTU

Dimensions & Utilities

• Cooking grid: 25¹⁄₂ in. W x 24¹⁄₂ in. D
• Overall: 36 in. W x 42⁵/₈ in. D x 77¹/₈ in. H
• Uses natural gas
• 1¹⁄₄-in. rear gas connection

*Free shipping on Vulcan VIR1F within the 48 contiguous states.

From The Manufacturer

V Series Deck-Broiler, Heavy Duty range match, Gas, single deck infrared burners, 25-1/2" x 24-1/2 cooking grid, spring balanced, 5 position grip, modular, stainless steel front, top front ledge & sides, 6" stainless steel legs, 1-1/4" front gas manifold, 100,000 BTU, natural gas

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan VIR1F Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
