Vulcan HEG24E 24" Electric Griddle w/ Thermostatic Controls - 1/2" Steel Plate, 240v/3ph

The Vulcan HEG24E electric countertop griddle measures 24 inches in width and has four sheathed heating elements. With two individual thermostat controls, the griddle can be set for separate cook zones so users can fry eggs on one side and cook burgers or chicken on the other. Each thermostat is protected with a chromed guard that resists corrosion and prevents accidental temperature adjustments. To prepare a wide variety of foods, the griddle has a temperature range of 200 to 450 degrees Fahrenheit.

Extending time between cleaning, the Vulcan HEG24E electric griddle’s grease drawer can hold as much as 1.5 gallons of fat drippings before it needs to be emptied. Streamlining use, the griddle’s front grease trough measures 3¹⁄₂ inches wide, which is large enough to accommodate most spatulas. Preventing burns, the griddle’s bull-nose front has a stay-cool design that resists heat transfer during cooking.

Product Details

• Countertop model
• Front and sides are made of durable stainless steel
• Temperature range: 200-450 degrees F
• 4 sheathed heating elements
• 2 cycling lights
• Separately controlled burners enable dual cook zones
• 2 thermostats are bottom mounted and snap activated
• Chromed thermostat knob guards prevent accidental adjustments
• Cool bull-nose design on front grease trough prevents burns
• ¹⁄₂-in.-thick polished griddle plate resists warping
• 4-in. rear grease splash with wraparound tapered sides
• Grease gutter is 3¹⁄₂-in. wide
• 1.5-gal. grease drawer holds fat drippings
• Low-profile, 11-in. cooking height
• 4-in. adjustable stainless steel legs

Dimensions & Utilities

• Cook surface: 24 in. W x 24 in. D
• Overall : 24 in. W x 31¹/₂ in. D x 15³/₁₀ in. H
• 10.8 kW
• 240 V/50-60 Hz/3 ph

*Free shipping on Vulcan HEG24E within the 48 contiguous states.

From The Manufacturer

Heavy Duty Griddle, electric, countertop, 24" W x 24" D cooking surface, 1/2" thick polished steel griddle plate, bottom mounted snap action thermostat every 12", low profile, stainless steel front, sides, front top ledge with "Cool Bullnose", front grease trough, 4" back & tapered side splashes, 4" adjustable legs, cCSAus, NSF

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan HEG24E Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.

Documents

Spec Sheet

Warranty

Service Manual

Parts Breakdown

Manual

Catalog
