Vulcan HEG24E 24" Electric Griddle w/ Thermostatic Controls - 1/2" Steel Plate, 240v/1ph

To fit comfortably on top of a counter or tabletop, the Vulcan HEG24E electric griddle measures 24 inches wide by 31¹/₂ inches deep and has a low-profile cook height of 11 inches for accessibility. It has four sheathed heating elements that are individually controlled to enable dual cook zones. Setting different temperatures for each side of the griddle enables users to toast buns, fry bacon, and cook burgers all at the same time. For long-term use in high-volume settings, the unit’s front and sides are made of stainless steel.

Protecting the Vulcan HEG24E electric griddle’s thermostat knobs, chromed guards block the controls from impact to prevent accidental adjustments. The thermostats are bottom mounted and accessible from the front, while the griddle rests on 4-inch adjustable stainless steel legs. Also front mounted, the unit’s grease trough measures 3¹⁄₂ inches in width and drains into a grease drawer that holds as much as 1.5 gallons of oily runoff. Protecting neighboring surfaces, the griddle has a 4-inch rear splash with tapered side splashes.

Product Details

• Countertop model
• Rust-resistant stainless steel front and sides
• Temperature range: 200-450 degrees F
• 4 sheathed heating elements
• 2 cycling lights
• Dual cook zones feature individually controlled burners
• 2 snap-action thermostats are bottom mounted
• Corrosion-resistant chromed thermostat knob guards are heavy duty
• Front grease trough has a cool bull-nose design to prevent burns
• Polished griddle plate is ¹⁄₂-in. thick
• Wraparound grease splash is 4 in. high with tapered sides
• Wide 3¹⁄₂-in. grease gutter
• 1.5-gal. grease drawer
• Low-profile, 11-in. cooking height
• 4-in. adjustable stainless steel legs

Dimensions & Utilities

• Cook surface: 24 in. W x 24 in. D
• Overall: 24 in. W x 31¹/₂ in. D x 15³/₁₀ in. H
• 10.8 kW
• 240 V/50-60 Hz/1 ph

*Free shipping on Vulcan HEG24E within the 48 contiguous states.

From The Manufacturer

Heavy Duty Griddle, electric, countertop, 24" W x 24" D cooking surface, 1/2" thick polished steel griddle plate, bottom mounted snap action thermostat every 12", low profile, stainless steel front, sides, front top ledge with "Cool Bullnose", front grease trough, 4" back & tapered side splashes, 4" adjustable legs, cCSAus, NSF

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan HEG24E Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
