Vulcan EV48S-4HT208 48" EV Series Electric Range w/ (4) Hot Tops, 208v/1ph/3ph

Featuring (4) 12-inch by 24-inch thermostatically controlled hot top sections, the Vulcan EV48S-4HT208 EV Series electric range is built to support large-scale cooking operations with consistent surface heat. Each solid top section provides broad contact for pots and pans and helps distribute heat evenly across the surface. A full-width stainless steel crumb tray beneath the cooking surface catches debris, while the single-deck high shelf offers a staging area for cookware or supplies. The welded aluminized steel frame reinforces structural stability in demanding environments.

The Vulcan EV48S-4HT208 electric range includes a standard oversized oven, which features an interior measuring 26¹⁄₂ inches wide by 26³⁄₈ inches deep by 14 inches high—large enough to accommodate full-size 18-in. x 26-in. sheet pans loaded either front to back or side to side. The oven includes one rack with three possible positions and a top browning control for finishing dishes. Thermostat settings range from 200 and 500 degrees Fahrenheit. Overall, this unit measures 48 inches wide by 34 inches deep by 58 inches high, making it a good option for high-output kitchens that require flexibility without sacrificing floor space. Stainless steel construction throughout the body, shelf, and legs offers corrosion resistance, and 6-in. adjustable legs ensure stability across uneven surfaces.

Product Details

• EV Series
• 48-in.-wide electric range
• Stainless steel construction
• Welded aluminized steel frame
• (4) 12-in. x 24-in. hot tops
• Thermostatic surface controls
• Standard oversized oven with top browning control
• 1 oven rack with 3 rack positions
• Full-width pull-out crumb tray
• Cool-to-the-touch control knobs
• Single-deck high shelf
• 6-in. adjustable stainless steel legs

Dimensions & Utilities

• Overall: 48 in. W x 34 in. D x 58 in. H
• Interior: 26¹⁄₂ in. W x 26³⁄₈ in. D x 14 in. H
• 208 V/60 Hz/1 or 3 ph (convertible phase)

Product Features

*Free shipping on Vulcan EV48S-4HT208 within the 48 contiguous states.

From The Manufacturer

Restaurant Range, electric, 48", (4) hot tops, thermostatic controls, 5.0 kW standard oversized oven with (1) rack, stainless steel front, sides, single-deck high shelf, 6" legs, cCSAus, NSF, 208v

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan EV48S-4HT208 Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
