Vulcan EV36S-6FP480 60" EV Series Electric Range w/ (6) French Hot Plates, 480v/1ph/3ph

Featuring six French plates and a full-width crumb tray, the Vulcan EV36-S-6FP-480 electric range is simple to clean at closing time. Its front, sides, riser, shelf, and legs are all made of stainless steel for smooth cleaning. For user comfort, the control knobs are made of heat-resistant material, staying cool despite constant use. An infinite heat switch is paired with each burner and, using its four quick-adjustment positions, chefs can prevent food from burning.

This Vulcan EV36-S-6FP-480 electric range has a convenient oven base where users can brown foods after cooking. To accommodate various products, this oven includes a browning control, an adjustable thermostat, and a three-position rack; this large rack holds 18-inch by 26-inch sheet pans running side to side or front to back. For heavy-duty durability, this unit has many stainless steel components and an MIG-welded, aluminized steel frame. Its legs are adjustable and steady the unit on uneven floors.

Product Details

• 9¹⁄₂-in.-diameter, round French plates
• Individual infinite heat switches for cooking multiple foods at a time
• 1 oven rack is adjustable to 3 positions
• Full-width, stainless steel crumb tray catches messes from the top
• Standard oven holds a 26-in. x 18-in. pan in either configuration
• Top browning control for finishing dishes
• Cool-to-the-touch control knobs
• Oven temperature range: 200-500 degrees F
• Sturdy, stainless steel front, sides, legs, shelf, and rear riser
• Frame is fully MIG welded to increase durability
• 6-in. adjustable legs

Dimensions & Utilities

• Oven Interior: 26¹⁄₂ in. W x 26³⁄₈ in. D x 14 in. H
• Overall: 36 in. W x 34 in. D x 58 in. H
• 23.5 A, 17 kW
• 480 V/60 Hz/3 ph

*Free shipping on Vulcan EV36S-6FP480 within the 48 contiguous states.

From The Manufacturer

Restaurant Range, electric, 36", (6) 2.0 kW French hotplates, infinite controls, standard oversized oven, includes (1) rack, stainless steel front, sides, single-deck high shelf & 6" legs, 480v

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor

Vulcan EV36S-6FP480 Specifications

Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
