Vulcan 4VK85AF Gas Fryer - (4) 90 lb Vats, Floor Model, Natural Gas

A four-battery unit, the 4VK85AF gas fryer can hold 85 to 90 pounds of oil per frypot. For fluid, quick heating while conserving energy, its SoftStart™ ignition system outputs 35,000 BTU per hour, and when the fryer reaches desired temperatures, it can maintain the heat with just 6,298 BTUs when idle. Its FivePass™ heat transference system uniformly distributes heat to prevent scalding. This high-efficiency fryer is integrated with KleenScreen Plus® filtration to extend oil life and reduce premature refilling. Its ¹/₃-horsepower motor and pump work in tandem to circulate frying compound at 8 gallons per minute; for ample screening, its stainless steel filtration mesh screen covers 270 and 350 square inches.

This fryer is powered by natural gas and operated with independent solid-state analog controls that are located behind the door of each cabinet. Temperatures can be adjusted between 200 and 390 degrees Fahrenheit, and this unit has user-selectable fat melt modes to provide additional flexibility. Should it exceed safe temperatures, its hi-limit shut-off cuts off the burners.

The Vulcan 4VK85AF gas fryer measures 84 inches wide by 34³/₈inches deep by 47¹/₄ inches high. Its fry tank and cabinet are constructed of durable stainless steel, which is ideal for high-intensity back-of-house kitchens. Each frypot includes metal twin baskets that feature plastic-coated handles to reduce heat transfer to employees' palms, and to maneuver this heavy-duty unit as needed, it sits on four 6-inch casters. For precise cleaning, a tank brush and clean-out rod are included.

Product Details

• Part of the PowerFry5™ series
• 85-90-lb. capacity per frypot
• 4 frypots
• 8 fry baskets with plastic-coated handles (2 per vat)
• Stainless steel cabinet and fry tank
• Adjustable casters (2 swivel locking & 2 non-locking)
• 1¹/₄-in. full port ball type drain valve
• Includes tank brush and clean-out rod
• SoftStart ignition system quickly heats oil at reduced BTU rate
• FivePass heat transfer system
• (4) 90,000 BTUs

Solid-state Analog Controls

• Temperature range: 200-390 degrees F
• Fat-melt modes are user selectable
• Hi-limit shut off

KleenScreen PLUS Filtration System

• Motor and pump circulate compound at 8 gal. per minute
• 18-ga. stainless steel filter pan
• Two-sided stainless steel mesh filter
• Boil-out bypass function
• 1¹/₄-in. port ball type drain valve
• Interlock switch

Dimensions & Utilities

• Tank size: (4) 19¹/₂ in. W x 18¹/₄ in. D
• Baskets: (8) 8³/₄ in. W x 16³/₄ in. D x 6 in. H
• Overall: 84 in. W x 34³/₈ in. D x 47¹/₄ in. H
• 120 V/60 Hz/1 ph, with NEMA 5-15 P
• 7 A, ¹/₃-HP motor
• 1¹/₄ NPT common rear gas connection
• Powered by natural gas

Product Features

*Free shipping on Vulcan 4VK85AF within the 48 contiguous states.

From The Manufacturer

PowerFry5™ Fryer, natural gas, high efficiency, 84" W, (4) battery, 85-90 lbs. capacity per vat, solid state analog knob control with melt cycles, FivePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, adjustable casters (2 swivel locking & 2 non-locking), 360,000 BTU, CSA, NSF, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

Vulcan 4VK85AF Specifications

Spec Attribute	Spec Value
Manufacturer	Vulcan
Baskets	2
BTU per Fryer	90000
Capacity (lbs)	360
Food Type	Breaded
Frypot Style	Tube Type
Gas Type	NG
NEMA	5-15P
Number of Fry Pots	4
Oil Capacity (lb)	360
Oil Capacity/Fryer (lb)	90
Product	Gas Fryers
Product Type	Cooking Equipment
Rating	Best
Series	PowerFry5™
Type	Floor Model
Warranty	1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)	84
Weight	1236.00
