Vulcan 4VK65DF Gas Fryer - (4) 70 lb Vats, Floor Model, Natural Gas

The Vulcan 4VK65DF floor model gas fryer is a four-battery unit powered by natural gas and featuring an integrated KleenScreen Plus® filtration system. Each vat can hold 65 to 70 pounds of oil, and to extend oil life, it filtrates the frying compound at 8 gallons per minute. Its stainless steel mesh filter screens from two sides to cover 270 and 350 square inches, and once the oil is emptied through its 1¹/₄-inch drain valve, the 18-gauge filter pan can hold 110 pounds. To clean the exterior, this unit includes a tank brush and clean-out rod.

Overall, this unit measures 84 inches wide by 30¹/₈ inches deep by 47¹/₄ inches high and is mounted on 6-inch casters, easing maneuvering on smooth or irregular floors alike. Its 19¹/₂-inch-wide by 14-inch-deep fry tank is made of stainless steel for a durable and corrosion-resistant design. It comes with metal-constructed fry baskets (2 per frypot) that feature plastic-coated handles to reduce heat transfer to palms.

To cook high volumes of breaded meats or vegetables, the Vulcan 4VK65DF fryer unit upholds temperatures between 200 and 390 degrees Fahrenheit; for precise temperature control, it's operated with solid-state digital controls. If it exceeds its temperature limit, it has a hi-limit shutoff to reduce fire risks. It produces 320,000 BTUs total, but to conserve energy, its SoftStart™ ignition heats the system at just half that rate. Meanwhile, its FivePass™ heat transfer yields 78 percent thermal efficiency and 68 percent cooking efficiency.

Product Details

• Part of the PowerFry5™ series
• 4 vats with 65-70-lb. capacity
• 8 twin baskets with plastic handles (2 per frypot)
• Stainless steel cabinet and fry tank
• Adjustable casters (2 swivel locking & 2 non-locking)
• 1¹/₄-in. full port ball type drain valve
• Includes tank brush and clean-out rod
• SoftStart ignition system quickly heats oil at half the normal BTUs
• FivePass heat transfer system evenly heats oil
• (4) 80,000 BTUs

Solid-state Digital Controls

• Temperature control: 200-390 degrees F
• Can cook with actual time or compensating time
• Three fat melt modes
• Hi-limit shutoff

KleenScreen PLUS Filtration System

• Motor and pump circulate oil at 8 gal. per minute
• 18-ga. stainless steel filter pan
• Two-sided stainless steel filter mesh screen
• Boil-out bypass function
• Interlock switch shuts off burners during filtration

Dimensions & Utilities

• Tank size: (4) 19¹/₂ in. W x 14 in. D
• Baskets: (8) 9¹/₄ in. W x 13¹/₄ in. D x 6 in. H
• Overall: 84 in. W x 30¹/₈ in. D x 47¹/₄ in. H
• 120 V/60 Hz/1 ph, with NEMA 5-15 P
• 7 A, ¹/₃-HP motor
• 1¹/₄ NPT common rear gas connection
• Powered by natural gas

Product Features

*Free shipping on Vulcan 4VK65DF within the 48 contiguous states.

From The Manufacturer

PowerFry5™ Fryer, natural gas, high efficiency, 84" W, (4) battery, 65-70 lbs. capacity per vat, solid state digital control with melt cycles, FivePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, adjustable casters (2 swivel locking & 2 non-locking), 320,000 BTU, CSA, NSF, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

Vulcan 4VK65DF Specifications

Spec Attribute	Spec Value
Manufacturer	Vulcan
Baskets	2
BTU per Fryer	320000
Capacity (lbs)	280
Food Type	Breaded
Frypot Style	Tube Type
Gas Type	NG
NEMA	5-15P
Number of Fry Pots	4
Oil Capacity (lb)	280
Oil Capacity/Fryer (lb)	70
Product	Gas Fryers
Product Type	Cooking Equipment
Rating	Best
Series	PowerFry5™
Type	Floor Model
Warranty	1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)	84
Weight	1136.00
