Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
Vulcan 3VK45DF Gas Fryer - (3) 50 lb Vats, Floor Model, Liquid Propane
Typically ships in 2 - 3 weeks
Free Shipping Item
Retail Price: $113,531.00
$46,735.00 /Each
Selected Gas Type: Liquid Propane
Natural Gas
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Vulcan 3VK45DF Description
Part of the PowerFry5™ series, the Vulcan 3VK45DF freestanding commercial fryer is built to save energy and extend oil life because its integrated FivePass™ heat transfer system uniformly distributes heat throughout the oil. This mechanism minimizes cooking times, decreases lag between recoveries, and yields 66 percent cooking efficiency and 78 percent thermal efficiency. The SoftStart™ ignition system heats oil by outputting 35,000 BTUs per hour—half the unit's maximum hourly BTU output—to reduce energy usage and prolong oil life. Its idle temperature setting maintains the desired heat by only outputting 4,251 BTUs per hour. Employees can set all three frypots' temperatures between 200 and 390, choose from three melt cycles, initiate two countdown timers, and select to use actual or compensating time. A digital display provides readouts of temperatures in Celsius and Fahrenheit so staff can monitor the heating process.
By working with the integrated energy-saving processes, the KleenScreen PLUS® filtration collection further extends oil quality. This unit is designed to be used twice a day to maintain clean, good-tasting oil, and its one-touch button simplifies startup. As much as 70 pounds of oil can be stored in its drawn stainless steel filtration pan. While the pump and motor circulate oil at 8 gallons per minute, its stainless steel mesh filter screen filters debris from two sides. Once filtering is complete, the oil-return tube returns it back to the frypots.
For durability, the Vulcan 3VK45DF commercial gas fryer's body, frypots, and fryer baskets are made of rugged, rust- and scratch-resistant stainless steel. While its 471⁄8-inch-tall structure creates a 361⁄4-inch working height, the 461⁄2-inch-wide by 301⁄8-inch-deep base is mounted on four 6-inch casters. Two of these casters include brakes to secure it in place during use.
Product Details
- Part of the PowerFry5 line
- Freestanding with (3) 50-lb. fry tanks
- SoftStart ignition system only outputs 35,000 BTUs to save energy and quickly heat oil
- FivePass heat transfer system enhances cooking and thermal efficiency
- Energy-efficient idle temperature setting
- Flue temperature remains below 500 degrees F at maximum production rate
- Hi-limit shutoff
- Stainless steel body, frypots, and fryer baskets
- 6 fryer baskets with plastic-coated handles (2 baskets per frypot)
- (4) 6-in. adjustable casters (2 with locks)
- Includes clean-out rod for drain and tank brush
- 11⁄4-in. port ball-type drain valve
- 6-in. clearance required at sides and rear when placed near combustible construction
- 16-in. minimum clearance to adjacent open-top burner units
- (3) 70,000 BTU
Solid-state Digital Controls
- Electronic matchless ignition
- Digital display in Fahrenheit or Celsius
- Operating temperature range: 200-390 degrees F
- 3 melt modes
- 2 countdown timers
- Automatic boil-out mode
- Can cook with compensating time or actual time
Filtration System Details
- 1-touch button initiates filtration cycle
- Seamless, lightweight 18-ga. stainless steel filtration pan features 70-lb. oil capacity
- Pump and motor circulate oil at 8 GPM
- Stainless steel mesh filter establishes 270-350-sq.-in. filtration area
- Drain valve interlock switch
- Hands-free oil-return tube
Dimensions & Utilities
- 461⁄2 in. W x 301⁄8 in. D x 471⁄8 in. H
- 7 A, 1⁄3 HP
- 115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
- Powered by LP gas
- 11⁄4-in. NPT common rear gas connection
Product Features
*Free shipping on Vulcan 3VK45DF within the 48 contiguous states.
From The Manufacturer
PowerFry5™ Fryer, LP gas, high efficiency, 46-1/2" W, (3) battery, 45-50 lbs. capacity per vat, solid state digital control with melt cycles, FivePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, adjustable casters (2 swivel locking & 2 non-locking), 210,000 BTU, CSA, NSF, ENERGY STAR®
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor; 10-year Fry Tank
Vulcan 3VK45DF Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 70000 |
| Capacity (lbs) | 150 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | LP |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | PowerFry5™ |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 46.5 |
| Weight | 717.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
