Vulcan 3TR45DF Gas Fryer - (3) 50 lb Vats, Floor Model, Natural Gas

The Vulcan 3TR45DF gas fryer measures 46¹/₂ inches wide by 30¹/₈ inches deep by 47¹/₄ inches high and sits on a set of four 6-inch casters. It features three 14-inch-wide by 14-inch-deep fry tanks and cabinets made of stainless steel to withstand aggressive settings with enhanced durability and corrosion resistance. This three-battery unit's vats each hold 45 to 50 pounds of oil.

This unit maintains even heating with its ThreePass™ heat transfer system, which yields 72 percent thermal efficiency and 60.9 percent cooking efficiency. It outputs 210,000 BTU total, but its SoftStart™ electronic ignition lowers output to 105,000 BTU per hour during startup to conserve energy and prevent scorching. To increase oil life, its KleenScreen PLUS® filtration system circulates oil at 8 gallons per minute through its stainless steel mesh screen. For employee safety, its interlock switch turns off the gas burners while filtering the oil.

With its digital controls, operators can adjust temperatures from 200 to 390 degrees Fahrenheit. To streamline cleaning, the Vulcan 3TR45DF gas fryer features a 1¹/₄-inch port ball type drain valve for emptying oil quickly and without hassle. For efficient cleaning after use, it includes a tank brush, auto boil-out mode, and clean-out rod.

Product Details

• Part of the PowerFry3™ series
• 3 fry pots
• Fry pot capacity: 45-50 lb. (135-150 lb. total)
• (4) 6-in. adjustable casters
• Stainless steel cabinet and fry tank
• Includes tank brush and clean-out rod

Heat System Details

• Temperature range: 200-390 degrees F
• Solid-state digital control
• 2 countdown timers can track compensating or actual time to account for temperature fluctuations
• 3 melt modes for different shortening types
• Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
• ThreePass heat transfer system
• Twin baskets feature plastic-coated handles
• SoftStart electric ignition system

Integrated Filtration System

• KleenScreen PLUS filtration
• 18-ga. stainless steel filter pan
• Stainless steel filter mesh screen
• Auto boil-out mode
• Drain valve interlock switch
• 1¹/₄-in. port ball type drain valve

Dimensions & Utilities

• Twin baskets: 6¹/₂ in. W x 13¹/₄ in. D x 6 in. H
• Fry tanks: 14 in. W x 14 in. D
• Overall: 46¹/₂ in. W x 30¹/₈ in. D x 47¹/₄ in. H
• 6 A, 1/₃ HP
• 115 V/60 Hz/1 ph
• Natural gas powered
• 210,000 BTU

Product Features

*Free shipping on Vulcan 3TR45DF within the 48 contiguous states.

From The Manufacturer

PowerFry3™ Fryer, natural gas, high efficiency, 46-1/2" W, (3) battery, 45-50 lbs. capacity per vat, solid state digital control with melt cycles, ThreePass™ heat transfer system, electronic ignition, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, adjustable casters (2 swivel locking & 2 non-locking), 210,000 BTU, CSA, NSF, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

Vulcan 3TR45DF Specifications

Spec Attribute	Spec Value
Manufacturer	Vulcan
Baskets	2
BTU per Fryer	70000
Capacity (lbs)	150
Food Type	Breaded
Frypot Style	Tube Type
Gas Type	NG
NEMA	5-15P
Number of Fry Pots	3
Oil Capacity (lb)	150
Oil Capacity/Fryer (lb)	50
Product	Gas Fryers
Product Type	Cooking Equipment
Rating	Best
Series	PowerFry3™
Type	Floor Model
Warranty	1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)	46.5
Weight	717.00
