Vulcan started producing equipment in Louisville Ky., more than 150 years ago. Today, the brand produces state-of-the-art cooking appliances, including fryers, ovens, and everything in between. The brand is owned by Illinois Tool Works, a global manufacturing leader.
Vulcan 3GR45MF Gas Fryer - (3) 50 lb Vats, Floor Model, Natural Gas
Typically ships in 9 - 13 Business Days
Free Shipping Item
Retail Price: $76,475.19
$31,481.00 /Each
Selected Gas Type: Natural Gas
Liquid Propane
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Looking for ENERGY STAR® Commercial Gas Fryers?
See our selection of Vulcan ENERGY STAR® Commercial Gas Fryers below
Previous
Next
Vulcan 3GR45MF Description
The Vulcan 3GR45MF gas fryer is constructed of durable stainless steel to withstand continuous use in commercial kitchens. Designed with three batteries, each capable of holding 45 to 50 pounds of oil, it operates with natural gas at 360,000 BTUs per hour. It comes with twin fry baskets to ease loading and unloading products; the handles are coated in plastic to minimize heat transfer. For mobility to ease cleaning and maintenance, this freestanding unit sits on four 6-inch casters, two of which can lock for static placement. Built with a V-shaped cold zone, sediments can be collected without burning, and for even heat distribution, it features four heat exchanger tubes. Overall, it measures 461/2 inches wide by 301/8 inches deep by 461/4 inches high.
Because the Vulcan 3GR45MF deep commercial fryer uses the Kleenscreen Plus® filtration system, operators can prolong the oil's life with minimal flavor transfer. This system uses a stainless steel mesh screen to filter particulates out of the oil and recirculate it for reuse. The filter pan sits on drawer slides and is made of 18-gauge stainless steel with handles for durability, and to facilitate dumping, the pan and filter are dishwasher safe. For simple oil drainage, the 11/4-inch drain valve offers an interlock switch, powering off gas burners automatically when the drain is open. This model has a clean-out rod, tank brush, and stainless steel crumb scoop to ease thorough cleaning. It also features a Boil Out ByPass™ system that boils water and cleaning solution in the vats, which can be drained afterward without impacting other fryer components.
Product Details
- Vat capacity: 45 to 50 lb.
- 3 batteries
- Freestanding unit
- Twin fry baskets featuring plastic-coated handles
- Cabinet and tank are constructed of stainless steel
- V-shaped cold zone gathers loose sediment
- 4 heat exchanger tubes placed for simple cleaning
- (4) 6-in. casters (2 lockable)
- Hi-limit shut off turns off gas when oil is too hot
- Millivolt thermostat control temperature range: 200 to 400 degrees F
- Combination gas shut-off valve and pilot safety system
- 11/4-in. full-port, ball-type drain valve
- Includes tank brush, stainless steel crumb scoop, and clean-out rod
- 360,000 BTU
Kleenscreen Plus Filtration System
- Drain valve interlock switch automatically powers off gas burners when valve is opened
- 201/2-lb. 18-ga. stainless steel filter pan is seamless
- 270-sq-in. stainless steel mesh filter screen is double sided
- Boil Out ByPass removes boil-out solution from vat
- Filter pan and screen are dishwasher safe
- Pan has lift handles and is placed on drawer slides for simple handling
- Motor and pump circulate oil at 8 gallons per minute
- One-touch push-button switch activates filter pump controls
- High-temperature discard hose
Dimensions & Utilities
- Overall: 461/2 in. W x 301/8 in. D x 461/8 in. H
- Natural gas
- 6 A, 1/3 HP
- 120 V/60 Hz/1 ph, includes cord with NEMA 5-15P plug
- 1/2-in. ID and 3/4-in. OD rear gas connection
Product Features
*Free shipping on Vulcan 3GR45MF within the 48 contiguous states.
From The Manufacturer
Fryer, gas, 46-1/2" W, (3) battery, 45-50 lb. capacity per vat, millivolt thermostat controls, KleenScreen Plus® filtration system, twin baskets, stainless steel cabinet and fry tank, adjustable casters (2 swivel locking & 2 non-locking), 360,000 BTU, CSA Star, CSA Flame, NSF
*Image may not depict product color, inclusions or accessories.
1-year Limited Parts & Labor; 10-year Fry Tank
Vulcan 3GR45MF Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Baskets | 2 |
| BTU per Fryer | 120000 |
| Capacity (lbs) | 150 |
| Food Type | Breaded |
| Frypot Style | Tube Type |
| Gas Type | NG |
| NEMA | 5-15P |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Product | Gas Fryers |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | 3GR45M Series |
| Type | Floor Model |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Width (in) | 46.5 |
| Weight | 695.00 |
Residential Users: This unit is not to be installed or operated in a residential or other non-commercial setting. Check local codes to ensure your foodservice kitchen is properly equipped for this piece. Use in an improper setting will void the warranty and the manufacturer will not provide parts or labor coverage for damage, failure, or other issues with the product. While this product may be covered by a manufacturer's warranty, vendor assumes no liability for product failure or any damages/injuries.
WARNING: Important Prop 65 information for California residents.
