Vulcan 3ER50AF Electric Fryer - (3) 50 lb Vats, Floor Model, 208v/3ph
Typically ships in 3 - 4 weeks
Retail Price: $93,610.00
$38,535.00 /Each
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Vulcan 3ER50AF Description
Made with a 16-gauge stainless steel fry tank, the Vulcan 3ER50AF electric fryer provides lasting durability in commercial kitchens. This floor model fryer features three 50-pound vats, offering a total oil capacity of 150 pounds for high-volume frying operations. The solid-state analog knob control allows precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. Multiple fat melt modes support controlled oil heating, while the low-watt density ribbon-style heating elements provide fast heat recovery and energy efficiency.
Designed for effective oil filtration, the Vulcan 3ER50AF fryer includes an 18-gauge stainless steel filter pan with a 70-pound frying compound capacity. The KleenScreen PLUS® filtration system captures food debris, extending oil life and reducing waste. A 11/4-inch full-port ball-type drain valve facilitates controlled oil removal, while the drain valve interlock switch automatically turns off heating elements when oil is drained or the elements are lifted for cleaning. The Boil-Out ByPass™ system enables operators to remove boil-out solution without contact with the drain manifold, filter pan, or motor/pump. The fryer is supported by four 6-inch adjustable legs for stability and height customization.
Product Details
- (3) 50-pound vats
- 150-pound total oil capacity
- Solid-state analog knob control
- Temperature range: 200-390 degrees F
- Multiple fat melt modes
- Fast heat recovery
- KleenScreen PLUS filtration system
- Boil-Out ByPass system
- 11/4-in. full-port ball-type drain valve
- Drain valve interlock switch
- Low-watt density ribbon-style heating elements
- 16-ga. stainless steel fry tank
- Seamless 18-ga. stainless steel filter pan
- Stainless steel cabinet
- 2 twin fry baskets with plastic-coated handles
- (4) 6-inch adjustable legs
Dimensions & Utilities
- 461/2 in. W x 343/8 in. D x 361/4 in. H
- 17 kW
- 208 V/60 Hz/3 ph
Product Features
*Free shipping on Vulcan 3ER50AF within the 48 contiguous states.
From The Manufacturer
Fryer, electric, 46-1/2" W, (3) battery, 50 lbs. capacity per vat, solid state analog knob control with melt cycles, KleenScreen PLUS® filtration system, twin baskets, stainless steel cabinet & fry tank, (4) adjustable legs, 208v/3, CSAus, NSF, ENERGY STAR®
*Image may not depict product color, inclusions or accessories.
Vulcan 3ER50AF Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Vulcan |
| Capacity (lbs) | 50 |
| Hertz | 60 |
| kW | 17 |
| Number of Fry Pots | 3 |
| Oil Capacity (lb) | 150 |
| Oil Capacity/Fryer (lb) | 50 |
| Phase | 3 |
| Rating | Best |
| Series | 3ER50 Series |
| Product Type | Cooking Equipment |
| Product | Electric Fryers |
| Voltage | 208 |
| Type | Floor Model |
| Width (in) | 46.5 |
| Warranty | 1-year Limited Parts & Labor; 10-year Fry Tank |
| Weight | 717.00 |
