Traulsen AHF232WP-FHG Full Height Insulated Heated Cabinet w/ (6) Pan Capacity, 208v/1ph
Typically ships in 4 - 6 weeks
$25,794.95 /Each
Contact us for details!
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Looking for ENERGY STAR® Heated Cabinet?
See our selection of Traulsen ENERGY STAR® Heated Cabinet below
Traulsen AHF232WP-FHG Description
The Traulsen AHF232WP-FHG insulated heated cabinet has two sections in its 58-inch-wide by 3715/16-inch-deep by 831/4-inch-high structure to accommodate food until it's served. It maintains temperatures from 135 to 180 degrees Fahrenheit, and it utilizes a ducted fan air distribution system for uniform heating. To further promote even heating, the six wire shelves have gaps that enable air to circulate through them and around product. These shelves can be adjusted to suit a range of applications.
When the doors on the Traulsen AHF232WP-FHG full-height heated cabinet are opened, incandescent lights are automatically activated to illuminate product. The cabinet has a pass-thru design with doors on each side to facilitate product retrieval. Due to the doors' glass construction, employees can view food held inside without letting energy escape. This unit contains high-density polyurethane insulation to further preserve energy and reduce heat loss.
Product Details
- Part of the Spec line
- Microprocessor controls
- Temperature range: 135-180 degrees F
- Pass-thru design
- 2 sections
- Standard-depth cabinet
- 6 adjustable wire shelves
- Automatically activated incandescent lights
- Full-height doors made of glass for interior view
- Self-closing doors
- Doors stay open 120 degrees
- Sturdy stainless steel exterior with an aluminum interior
- Ducted fan air distribution system
- 6-in. adjustable stainless steel legs
Dimensions & Utilities
- 58 in. W x 3715/16 in. D x 831/4 in. H
- 15.5 A, 3000 W
- 208 V/60 Hz/1 ph, 9-ft. cord with plug
*Free shipping on Traulsen AHF232WP-FHG within the 48 contiguous states.
From The Manufacturer
Spec-Line Heated Cabinet, Pass-thru, two-section, stainless steel exterior, aluminum interior, standard depth cabinet, full-height glass doors, with EZ-Clean Gaskets, (3) clear coated adjustable shelves per section, microprocessor controls, 6' adjustable stainless steel legs, cETLus, ETL-Sanitation
*Image may not depict product color, inclusions or accessories.
Traulsen AHF232WP-FHG Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Traulsen |
| Application | Heat Only |
| Construction | Stainless Steel |
| Control Location | Top |
| Controls | Digital |
| Cubic Feet | 52.8 |
| Depth (in) | 37.94 |
| Door Design | Full |
| Door Type | Glass |
| Heat | Electric |
| Height (in) | 83.25 |
| Hertz | 60 |
| Hinge Configuration | Left/Right |
| kW | 3 |
| Load Type | Pass Thru |
| No. of Doors | 4 |
| Pan Capacity | 6 |
| Phase | 1 |
| Product | Heated Cabinets |
| Product Type | Food Warming Equipment |
| Sections | 2 |
| Series | Spec-Line |
| Size | Full Height |
| Slide Type | Shelves |
| Type | Insulated |
| Voltage | 208 |
| Warranty | 6-year Parts & Labor; 7-year Compressor |
| Width (in) | 58 |
| Weight | 645.00 |
