Traulsen AHF132WP-HHS Full Height Insulated Heated Cabinet w/ (3) Pan Capacity, 208v/1ph
Typically ships in 4 - 6 weeks
$15,282.63 /Each
Contact us for details!
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
White Glove Delivery
Contact your sales rep for availability
Attention: Order by 06-01-2025 to save before the price increases!
Traulsen AHF132WP-HHS Description
To hold product in ideal conditions, the Traulsen AHF132WP-HHS full-height heated cabinet maintains temperatures of 135 to 180 degrees Fahrenheit, and it operates with a ducted fan air distribution system. Its half doors help preserve energy by providing access to one area while the other door remains closed. Built into both sides, these doors enable pass-thru use. They can self-close if an employee forgets, or they can be propped open to facilitate cabinet access.
The Traulsen AHF132WP-HHS insulated heated cabinet has three shelves to contain items, and to ensure even heating, the shelves have a wire construction. To provide durability, it has a stainless steel exterior and an aluminum interior, both of which are corrosion resistant. The cabinet contains high-density polyurethane insulation to help preserve warm air and energy.
Product Details
- Part of the Spec line
- Standard depth with 1 section
- Pass-thru cabinet facilitates access from either side
- Microprocessor controls
- Temperature range: 135-180 degrees F
- 3 adjustable shelves
- Shelves made of wire to promote airflow
- Interior lit with incandescent lights
- Rust-resistant stainless steel exterior
- Durable aluminum interior
- Ducted fan air distribution system
- Half-height solid doors
- Self-closing doors can be propped open 120 degrees
- Stabilized with 6-in. adjustable legs
Dimensions & Utilities
- 297/8 in. W x 3715/16 in. D x 831/4 in. H
- 7.8 A, 1500 W
- 208 V/60 Hz/1 ph, 9-ft. cord with plug
*Free shipping on Traulsen AHF132WP-HHS within the 48 contiguous states.
From The Manufacturer
Spec-Line Heated Cabinet, Pass-thru, one-section, stainless steel exterior, aluminum interior, standard depth cabinet, half-height doors, with EZ-Clean Gaskets, (3) clear coated adjustable shelves per section, microprocessor controls, 6' adjustable stainless steel legs, cETLus, ETL-Sanitation, ENERGY STAR®
*Image may not depict product color, inclusions or accessories.
Traulsen AHF132WP-HHS Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Traulsen |
| Application | Heat Only |
| Construction | Stainless Steel |
| Control Location | Top |
| Controls | Digital |
| Cubic Feet | 24.8 |
| Depth (in) | 37.94 |
| Door Design | Dutch |
| Door Type | Solid |
| Heat | Electric |
| Height (in) | 83.25 |
| Hertz | 60 |
| Hinge Configuration | Right |
| kW | 1.5 |
| Load Type | Pass Thru |
| NEMA | L14-20P |
| No. of Doors | 4 |
| Pan Capacity | 3 |
| Phase | 1 |
| Product | Heated Cabinets |
| Product Type | Food Warming Equipment |
| Sections | 1 |
| Series | Spec-Line |
| Size | Full Height |
| Slide Type | Shelves |
| Special Features | All Stainless Exterior |
| Type | Insulated |
| Voltage | 208 |
| Warranty | 6-year Parts & Labor; 7-year Compressor |
| Width (in) | 29.88 |
| Weight | 385.00 |
