Groen TDH-20C 5 gal. Steam Kettle - Manual Tilt, 2/3 Jacket, Liquid Propane

The Groen TDH-20C steam kettle has a 20-quart (5-gallon) capacity—a size that works well on the countertop but still provides large batch cooking of almost anything, from sauces and gravies to rice and pasta. The unit uses self-contained steam to cook food—providing a more even heat than a stock pot range and eliminating hot spots that lead to scorching—and so does not need to be hooked up to a boiler or generator. Water is filled in the hollow jacket, which extends up the bottom of the kettle body, covering two-thirds of it.

Emptying contents from this kettle is facilitated by a manual tilt mechanism; when the hand lever is pulled, the kettle body tilts and a pouring lip on the rim of the container directs contents into a 4-inch-deep pan below, which can fit under the body when it is tilted. The safety shut-off feature turns off the heat if it is tilted past 12 degrees, and when the unit is tilted at all, the gas supply shuts off.

Durable for high-volume use, the Groen TDH-20C tabletop tilting kettle is made of welded stainless steel. For additional strength, the rim is reinforced, preventing denting that could lead to fluctuating steam pressure. The steam-jacketed kettle comes with a mounting bracket, which holds a separately-sold faucet on the back side so operators can have a constant supply of water.

Product Details

• 20-qt. (5-gal.) capacity
• Self-contained steam source does not need an external boiler or generator
• Two-third jacketed around the bottom and filled with pure water
• Water is heated and turns into steam
• Operator can tilt the kettle body manually to empty contents
• Left- or right-mounted hand-tilt lever
• 4-in.-deep pan fits under tilted kettle body
• Reinforced rim has a welded-in pouring lip that directs food into the pan below without dripping
• 1-piece, welded, 304 stainless steel is heavy duty and corrosion resistant
• Tabletop model
• Includes rear-mount faucet bracket
• Maximum 50 PSI steam pressure
• 31,000 BTU

Control System

• Right-mounted in a water-resistant housing
• 10-level temperature control knob
• Approximate temperature range: 150-295 degrees F
• Thermostatic operation maintains the set temperature by turning the power on and off
• Power on/off switch
• Power indicator light
• Heating indicator light
• Low-water warning indicator light

Safety Features

• Low-water cut-off feature shuts off gas supply to burners if water level is too low
• High-limit pressure switch opens at 43 PSI, shutting down burners until pressure decreases
• Pressure relief valve releases jacket steam pressure if it exceeds 50 PSI
• Safety tilt cut-off feature shuts off heat when kettle body is tilted past 12 degrees
• Gas supply shuts off when body is tilted

Dimensions & Utilities

• 25³/₄ in. W x 30³/₈ in. D x 29¹/₄ in. H
• Uses LP gas

*Free shipping on Groen TDH-20C within the 48 contiguous states.

From The Manufacturer

Kettle, gas, table top, 20 quart capacity, 2/3 jacket, IPX6 water rated electronic Classic controls, 304 stainless steel liner, hand tilt, support console on right, stainless steel construction, 50 PSI, 0 - 2000' elevation, 31,000 BTU, cCSAus, NSF, Made in USA

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor/2000 Operating Hours; 10-year Hemisphere; 2-year Parts & Labor/4000 Operating Hours for K-12 School

Groen TDH-20C Specifications

Documents

Spec Sheet

Warranty

Manual
