Summit BIM68OSPUMP 14 7/8"W Top Hat Undercounter Ice Machine - 62 lbs/day, Air Cooled, Pump Drain, 115v

The Summit BIM68OSPUMP undercounter ice maker flaunts a chip- and scratch-resistant stainless steel exterior that's suitable for indoor and outdoor use. It's built with an internal drain pump that enables flexible placement as the unit doesn't need to be installed near a floor drain. Great for office breakrooms and residential settings, this ice maker produces 62 pounds of gourmet-style ice in 24 hours; its storage bin can hold 26 pounds of ice at one time. The produced ice measures 1¹⁄₈ inches wide by 1¹⁄₈ inches deep by 1¹⁄₄ inches high and is crystal clear for enhanced purity. Designed for freestanding or undercounter applications, this ice maker measures 14²²/₂₅ inches wide by 22⁶³⁄₁₀₀ inches deep by 33⁶³/₁₀₀ inches high overall and has 0.98-cubic-foot interior capacity.

To minimize build-up and reduce maintenance needs, the Summit BIM68OSPUMP undercounter ice maker has a frost-free operation system. This unit features an exterior fan that provides ventilation, and it effectively freezes inlet water using R134a refrigerant. For flexibility, the front door is field reversible, meaning it can be configured to open right-to-left or left-to-right; to exhibit a professional appearance, the door flaunts a horizontally mounted towel bar-style handle made of stainless steel. Its magnetic door catch keeps the door closed to minimize thermal loss.

Product Details

• 62-lb. maximum daily ice production
• 26-lb. maximum ice storage capacity
• 0.98-cu.-ft. interior capacity
• For built-in or freestanding configuration
• Durable stainless steel construction enables indoor or outdoor use
• Reversable stainless steel door
• Magnetic door catcher
• Pro-style horizontal handle
• Produces gourmet-style top hat ice
• Cube size: 1¹⁄₈ in. W x 1¹⁄₈ in. D x 1¹⁄₄ in. H
• Frost-free defrost system
• Built-in drain pump
• Exterior fan
• R134a refrigerant
• Operating pressure: 105-210 PSI
• ¹/₄-in. OD water supply

Dimensions & Utilities

• Interior: 12³⁄₄ in. W x 9¹⁄₄ in. D
• Overall: 14²²/₂₅ in. W x 22⁶³⁄₁₀₀ in. D x 33⁶³/₁₀₀ in. H
• 4 A
• 115 V/60 Hz/1 ph

Product Features

From The Manufacturer

Undercounter Ice Maker, built-in or freestanding, outdoor or indoor use, air-cooled, 14.88"W x 22.63"D x 33.63"H, 0.98 cu. ft. capacity, (62) lbs production/24 hours, (26) lbs holding capacity, front-breathing, reversible stainless steel door, pro style horizontal handle, magnetic door catch, clear gourmet dice style ice, internal pump, stainless steel exterior, ice scoop included, 115v/60/1-ph, ETL, cETL, ETL-Sanitation to NSF-12 (Commercial)

*Image may not depict product color, inclusions or accessories.

1-year Limited Parts & Labor; 5-year Compressor Parts

Summit BIM68OSPUMP Specifications

A division of Felix Stroch, Inc., Summit Appliance provides the largest collection of undercounter and ADA-compliant refrigeration products in the industry. It also provides a diverse selection of appliances for healthcare settings, hotels, and universities, as well as its own residential brand. Summit has been creating and developing products in its New York headquarters since 1969.

Documents

Spec Sheet

Manual

Brochure
