Ice-O-Matic ICE0400FW Description


Ice-O-Matic has replaced its ICE Series models with the CIM series, which is designed to be more user friendly, easier to clean, and more efficient. As part of this roll-out, this model has been replaced by the CIM0430FW, which can produce 460 pounds of full-cube ice per day.

Ice-O-Matic's ICE0400FW ice maker produces as much as 496 pounds of ice every 24 hours when installed where ambient air temperatures are no warmer than 70 degrees F and incoming water temperatures are 50 degrees F or cooler. The full-cube ice produced by the machine measures 78-inch in all dimensions, a size that makes the ice appropriate for serving liquor on ice as well as soft drinks and iced tea. The machine's evaporator plate is finished with a nickel plating that protects it from rust and premature failure caused by the constant exposure to water.

The machine's harvest assist technology uses a mechanical pin to push completed ice off of the evaporator plate, both improving the machine's ice production volume and reducing its energy consumption compared to similar machines with traditional harvest technologies. To protect the Ice-O-Matic ICE0400FW ice machine from premature failure due to mineral buildup from hard water, it is recommended that you connect it to either the IFQ1 manifold filter system or the IFI4C/IFI8C inline filter system. Doing so will also result in clearer, fresher-tasting ice.

Product Details

  • Produces as much as 496 lbs. of ice every 24 hr.
  • Full-cube ice measures 78-in. in each dimensions, an ideal format for premium beverages as well as soft drinks and iced tea
  • Pure Ice antimicrobial compound keeps interior surfaces clear of bacteria, mold, yeast, and slime for longer between ice machine cleanings
  • Nickel plating on evaporator plate protects that component from corrosion and general wear and tear
  • Manual harvest assist technology accelerates the ice harvest cycle, conserving energy and increasing the machine's daily production capacity
  • Constructed with corrosion- and damage-resistant stainless steel and textured, fingerprint-proof plastic for a long, durable life
  • For the longest machine life and the freshest-tasting ice, connect the machine to an Ice-O-Matic IFQ1 manifold filter system or an IFI4C/IFI8C inline filter system (each is sold separately).
  • Overall Dimensions: 30 in. W x 3312 in. D x 5314 in. H
  • 115 V/60 Hz/1 ph, 6.4 A
  • cULus and CE Listed; NSF Certified

ICE Series™ Modular Cube Ice Maker, water-cooled, approximately 496 lb production/24 hours, full-size cube, filter-free air, PURE ICE built in antimicrobial protection, Harvest assist produces Ice consistently/reduces operating cost, 115v/60/1-ph, 12.9 amps, cULus, NSF, CE

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Ice-O-Matic ICE0400FW Specifications

PDF Spec Sheet
Manufacturer Ice-O-Matic
24 Hr. Production (lbs) 496 lbs
Compressor Type Water Cooled
Depth (in) 24
Height (in) 20
Ice Type Full Cube
Specialty Options Antimicrobial System
Voltage 115/60/1
Width (in) 30
Warranty 3 years parts & labor/5 years evaporator & compressor
Weight 165.00
Ice-O-Matic ICE0400FW Certifications
  • UL
  • NSF
