Alto-Shaam AR-7H-SGLPANE Halo Heat® 1/2 Height Insulated Mobile Heated Cabinet w/ (8) Pan Capacity, 120v
Typically ships in 6 - 8 weeks
$7,053.60 /Each
Login or add to cart for more information!
Selected Voltage: 120V, 1 Phase
| 120V, 1 Phase |
| 208V, 1 Phase |
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Non Returnable Item
White Glove Delivery
Contact your sales rep for availability
Similar Products in Stock Now
Alto-Shaam AR-7H-SGLPANE Description
The Alto-Shaam AR-7H-SGLPANE 120 holding cabinet has a capacity for as many as eight full-size sheet pans. Designed as a companion piece for the AR-7E rotisserie oven, this equipment's attractive styling makes it suitable for use in front-of-house. It can be stacked with that rotisserie oven or other AR-7H holding cabinets.
This cabinet's manual controls allow internal temperatures to be adjusted from 60 to 200 degrees Fahrenheit. An external temperature display shows the cabinet's internal temperatures so staff can quickly verify that food is being held properly without continuing to cook it. Low-E glass resists transferring heat through the door to make this Alto-Shaam AR-7H-SGLPANE 120 holding cabinet an energy-efficient choice.
Product Details
- Designed as companion equipment to the Alto-Shaam AR-7E rotisserie oven
- Accommodates as many as 8 full-size, 18-in. x 26-in. pans
- Sleek style and design make oven appropriate for use behind a service line in front of house
- External temperature gauge displays internal air temperature
- Manual controls can adjust holding temperatures between 60 and 200 degrees F
- (4) 60-watt bulbs illuminate interior for an effective display
- 4 stainless steel wire shelves are adjustable on 16 positions
- Low-E glass resists the transfer of heat through door
- Ergonomic curved handle gives users a comfortable grip on door
- Cabinet is equipped with 5-in. casters, 2 of which are rigid and 2 of which swivel
- Can be stacked with other AR-7s or AR-7E rotisserie ovens
- Right-hinged door has a double-paned, curved-glass window
- 120 V/60 Hz/1 ph
- Overall Dimensions: 381⁄8 in. W x 321⁄16 in. D x 401⁄2 in. H
*Free shipping on Alto-Shaam AR-7H-SGLPANE within the 48 contiguous states.
From The Manufacturer
Halo Heat® Holding Cabinet, solid back, single compartment, (1) ON/OFF adjustable thermostat, individual light & temperature gauge, includes four (4) stainless steel wire shelves, pan capacity (8) 18" x 26" x 1", (16) 18" x 13" x 1", single pane flat glass right-hinged door, 5" casters - 2 rigid; 2 swivel with brakes, stainless steel exterior, EcoSmart®, cULus UL EPH ANSI/NSF 4, CE, TUV NORD
*Image may not depict product color, inclusions or accessories.
Alto-Shaam AR-7H-SGLPANE Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Alto-Shaam |
| Application | Heat Only |
| Construction | Stainless Steel |
| Control Location | Top |
| Controls | Dial |
| Depth (in) | 32.13 |
| Door Design | Full |
| Door Type | Glass |
| Heat | Electric |
| Height (in) | 40.5 |
| Hertz | 60 |
| Hinge Configuration | Right |
| kW | 1.8 |
| Load Type | Reach In |
| NEMA | 5-20P |
| No. of Doors | 1 |
| Pan Capacity | 8 |
| Phase | 1 |
| Product | Heated Cabinets |
| Product Type | Food Warming Equipment |
| Sections | 1 |
| Series | Halo Heat® |
| Size | 1/2 Height |
| Slide Spacing (in) | 2.94 |
| Slide Type | Fixed Wire |
| Special Features | All Stainless Exterior |
| Type | Insulated |
| Voltage | 120 |
| Warranty | 1-year Parts & Labor |
| Width (in) | 38.13 |
| Weight | 319.00 |
