Alto Shaam AR-7H-SGLPANE 1/2-Height Mobile Heated Cabinet w/ (8) Pan Capacity, 120v

Image may not depict product color, inclusions or accessories.

KaTom #: 139-AR7HSGLPANE120 • MPN: AR-7H-SGLPANE 120

Ships Free

Extended Lead Time (14+ days)

(0 reviews)Write a Review
Retail Price: $4,933.60

Selected Voltage: 120V, 1 Phase

120V, 1 Phase
208V, 1 Phase

Image may not depict product color, inclusions or accessories.

Alto Shaam AR-7H-SGLPANE Description

Alto Shaam

The Alto-Shaam AR-7H-SGLPANE 120 holding cabinet has a capacity for as many as eight full-size sheet pans. Designed as a companion piece for the AR-7E rotisserie oven, this equipment's attractive styling makes it suitable for use in front-of-house. It can be stacked with that rotisserie oven or other AR-7H holding cabinets.

This cabinet's manual controls allow internal temperatures to be adjusted from 60 to 200 degrees Fahrenheit. An external temperature display shows the cabinet's internal temperatures so staff can quickly verify that food is being held properly without continuing to cook it. Low-E glass resists transferring heat through the door to make this Alto-Shaam AR-7H-SGLPANE 120 holding cabinet an energy-efficient choice.

Product Details

  • Designed as companion equipment to the Alto-Shaam AR-7E rotisserie oven
  • Accommodates as many as 8 full-size, 18-in. x 26-in. pans
  • Sleek style and design make oven appropriate for use behind a service line in front of house
  • External temperature gauge displays internal air temperature
  • Manual controls can adjust holding temperatures between 60 and 200 degrees F
  • (4) 60-watt bulbs illuminate interior for an effective display
  • 4 stainless steel wire shelves are adjustable on 16 positions
  • Low-E glass resists the transfer of heat through door
  • Ergonomic curved handle gives users a comfortable grip on door
  • Cabinet is equipped with 5-in. casters, 2 of which are rigid and 2 of which swivel
  • Can be stacked with other AR-7s or AR-7E rotisserie ovens
  • 120 V/60 Hz/1 ph
  • Overall Dimensions: 3818 in. W x 32116 in. D x 4012 in. H
  • cULus, UL-EPH, and CE Listed

Halo Heat® Holding Cabinet, solid back, single compartment, (1) ON/OFF adjustable thermostat, individual light & temperature gauge, includes four (4) stainless steel wire shelves, pan capacity (8) 18" x 26" x 1", (16) 18" x 13" x 1", single pane flat glass door, 5" casters - 2 rigid; 2 swivel with brakes, stainless steel exterior, EcoSmart®, cULus UL EPH ANSI/NSF 4, CE, TUV NORD, 120v/60/1ph

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Alto Shaam AR-7H-SGLPANE Specifications

PDF Spec Sheet
Manufacturer Alto Shaam
Size 1/2 Height
Slide Type Fixed Wire
Type Insulated
No. of Doors 1
Door Type Glass
Load Type Reach In
Pan Capacity 8 Full Size
Construction Stainless Steel
Height (in) 40.5
Width (in) 38.13
Depth (in) 32.13
Slide Spacing 2.94"
Series Halo Heat®
Application Heat Only
Control Location Top
Controls Dial
Door Design Full
Specialty Options All Stainless Exterior
Voltage 120
Phase 1
Hertz 60
Weight 319.00
Alto Shaam AR-7H-SGLPANE Certifications
  • UL
  • NSF
