Turbo Air TOM-36DXB-N 36" Vertical Open Air Cooler w/ (5) Levels, 115v

Designed to increase impulse purchases in convenience stores, cafes, coffee shops, and more, the Turbo Air TOM-36DXB-N refrigerated merchandiser sports LED interior lighting, an LED advertising top panel, and four adjustable shelves on which operators can organize and display product. To preserve chill and improve efficiency, it's insulated with foamed-in-place polyurethane. With a total of 17.1 cubic feet of interior space, this unit measures 35⁵⁄₈ inches wide by 36 inches deep by 79 inches high overall.

The Turbo Air TOM-36DXB-N open-air cooler features a black exterior that blends in unobtrusively with existing equipment. To streamline operation, it features a digital thermometer and thermostat, while its self-contained refrigeration system simplifies installation. This unit operates with R290 hydrocarbon refrigerant to minimize its environmental impact. To reduce dust buildup that could negatively impact performance, it's equipped with a self-cleaning condenser.

Product Details

• Part of the TOM series
• 17.1-cu.-ft. interior space
• 4 adjustable shelves
• Interior and shelves are durable stainless steel
• LED interior lighting and advertising top panel
• Tempered glass front shield and sides
• Black exterior
• Backguard and perforated interior top and back wall improve airflow
• Foamed-in-place polyurethane insulation
• Digital thermometer and thermostat
• Self-contained refrigeration system
• Self-cleaning condenser device removes dust buildup
• Corrosion-resistant coated evaporator
• Front air intake with rear air discharge
• R290 hydrocarbon refrigerant
• Maximum ambient air temperature for operation: 75 degrees F
• Maximum relative humidity for operation: 55 percent

Dimensions & Utilities

• Shelves (4): 33¹⁄₈ in. W x 16 in. D
• Interior: 33¹⁄₄ in. W x 21¹⁄₄ in. D x 48³⁄₄ in. H
• Overall: 35⁵⁄₈ in. W x 36 in. D x 79 in. H
• 15.5 A, (2) ³⁄₄ HP
• 115 V/60 Hz/1 ph, 9⁷⁄₈-ft. cord with NEMA 5-20P plug

Product Features

From The Manufacturer

Extra Deep Vertical Open Display Merchandiser, 11 cu. ft. capacity, 36" W x 34 1/4" D X 78 7/8" H, bottom mount self-contained refrigeration, self-cleaning condenser device, LED advertising top panel, open front, tempered glass front shield & side walls, LED interior lighting, (4) adjustable stainless steel shelves, 300 stainless steel interior, non-peel anti-rust exterior coating, energy saving night curtain standard, plug-in installation, front air intake & rear air discharge, black exterior, R290 Hydrocarbon refrigerant, 115v/60/1-ph, (2) 3/4 HP, 15.5 amps, NEMA 5-20P, CSA-Sanitation, cCSAus

*Image may not depict product color, inclusions or accessories.

Additional Product Information

Natural Refrigerant

Product made with Hydrocarbon Refrigerants

2-year Parts & Labor; 5-year Limited Compressor Parts

Turbo Air TOM-36DXB-N Specifications

Documents

Spec Sheet

Warranty

Certifications
