Star 860MA 60" Ultra-Max® Gas Griddle w/ Manual Controls - 1" Steel Plate, Liquid Propane
$8,586.00 /Each
Call for details!
Selected Gas Type: Liquid Propane
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Star 860MA Description
Outfitted with five manual control knobs, the Star 860MA Ultra-Max® gas griddle gives operators direct adjustment over each burner zone for responsive line cooking. Its 60-inch-wide by 24-inch-deep cooking surface is made of 1-inch-thick polished steel, which absorbs and distributes heat efficiently during heavy-use applications. Star 860MA Ultra-Max gas griddle burners are spaced every 12 inches and deliver 30,000 BTU each using liquid propane, totaling 150,000 BTU across the unit. Each section includes a standing pilot to maintain burner readiness without relighting.
Grease management is streamlined in the Star 860MA Ultra-Max gas griddle with a 3 1⁄2-inch-wide trough that directs runoff into two 6-quart drawers, supporting extended operation between cleanings. A 4 3⁄8-inch wrap-around splash guard borders the rear and sides of the plate to limit surrounding mess. The unit is built with a welded steel frame and corrosion-resistant stainless steel exterior for durability in high-volume kitchens. Four 4-inch stainless steel legs adjust by 1 3⁄8 inches for proper leveling and it connects via a 3⁄4-inch NPT male gas inlet.
- Part of the Ultra-Max series
- 1-in.-thick polished steel griddle plate
- Manual controls with 12-in. spacing
- Welded steel frame with corrosion-resistant stainless steel exterior
- 4 3⁄8-in. tapered splash guard (rear and sides)
- 3 1⁄2-in. front grease trough
- (2) 6-qt. grease drawers
- Standing pilot ignition on each section
- Heavy-duty metal control knobs
- Includes (4) 4-in. stainless steel legs (adjustable by 1 3⁄8 in.)
- Overall dimensions: 60 in. W x 32 3⁄8 in. D x 18 in. H
- Cooking surface: 60 in. W x 24 in. D
- Powered by liquid propane
- 30,000 BTU per burner (150,000 total BTU)
- 3⁄4-in. NPT male gas connection
*Image may not depict product color, inclusions or accessories.
*Free shipping on Star 860MA within the 48 contiguous states.
From The Manufacturer
Ultra-Max® Griddle, countertop, gas, 60"W x 24"D cooking surface, 1" thick polished steel griddle plate, (5) manual controls, 4-3/8" tapered wrap-around splash guard, 3-1/2" front grease trough, 6 qt. grease drawer, heavy-duty metal knobs, standing pilot, welded steel frame with stainless steel exterior, 4" stainless steel legs with 1-3/8" adjustment, 150,000 BTU, cULus, UL EPH Classified
Star 860MA Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Star |
| Application | Medium Duty |
| BTU / Burner | 30000 |
| Control Spacing (in) | 12 |
| Controls | Manual |
| Cooking Area Depth (in) | 24 |
| Cooking Area Width (in) | 60 |
| Depth (in) | 32.38 |
| Gas Type | LP |
| Heat | Gas |
| Height (in) | 18 |
| Plate Material | Steel |
| Plate Thickness (in) | 1 |
| Product | Griddles |
| Product Type | Countertop Cooking Equipment |
| Rating | Best |
| Series | Ultra-Max® |
| Warranty | 2-year Parts & Labor |
| Width (in) | 60 |
| Weight | 656.00 |
