Blodgett CTB DBL Double Half Size Electric Convection Oven - 11.2kW, 208v/1ph
$23,961.00 /Each
Selected Voltage: 208V, 1 Phase
| 208V, 1 Phase |
| 208V, 3 Phase |
Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.
Blodgett CTB DBL Description
For quick rethermalizing, warming, baking, and roasting, the Blodgett CTB DBL electric convection oven is heated with two tubular heaters per baking compartment. A two-speed 1⁄4-horsepower motor powers its blower wheel, distributing the generated hot air. To simplify operation, staff can adjust temperatures from 200 to 500 degrees Fahrenheit on the solid-state thermostat as menus change, choose between cook and cool-down modes, and set the electro-mechanical timer. Solid mineral fiber insulation built into the top, back, sides, and bottom retain heat to minimize temperature fluctuations and energy loss.
This half-size Blodgett CTB DBL convection oven measures 30 1⁄4 inches wide by 25 1⁄8 inches deep by 69 1⁄8 inches tall. To accommodate various baking needs, it's divided into two baking chambers with five chrome-plated racks that accept five 13-inch by 18-inch half-size bake pans. Users can monitor browning by looking through the compartments' dual-pane thermal glass windows, and so employees can directly access product, both left-hinged doors open fully. While this oven's full angle-iron frame's front, top, sides, and back are corrosion-resistant stainless steel, its interior chambers are made of double-sided porcelain.
- Half-size unit with 2 decks
- Stainless steel top, sides, back, and base with full angle-iron frame
- Solid mineral fiber insulation built into top, back, sides, and bottom
- 1 door per section with chrome-plated door handles and dual-pane thermal glass windows
- Double-sided porcelain baking compartment liners
- Each baking chamber includes 5 removable, chrome-plated racks with 9 positions (spaced 1 5⁄8 in. apart)
- Capacity per section: (5) 18-in. x 13-in. pans
- 2 tubular heaters
- (2) 1⁄4-HP motors with automatic thermal overload protection
- 2-speed fan motors
- Operating temperature range: 200-500 degrees F
- Tilt-down modular control panel with recessed controls
- Solid-state infinite controls with time and thermostat dials
- Cook/cool-down mode selector
- 60-minute timer
- Control area cooling fans
- Vent riser
- Interiors: (2) 15 1⁄4 in. W x 20 in. D x 21 in. H
- Overall: 30 1⁄4 in. W x 25 1⁄8 in. D x 69 1⁄8 in. H
- 24 A, (2) 5.6 kW, (2) 1⁄4 HP
- 208 V/60 Hz/3 ph
*Image may not depict product color, inclusions or accessories.
*Free shipping on Blodgett CTB DBL within the 48 contiguous states.
From The Manufacturer
Convection Oven, electric, double-deck, half-size, capacity (5) 13" x 18" pans, (SSM) solid state infinite controls with separate dials for thermostat and timer, 2-speed fan, single door per deck, hinged on left, with dual pane thermal glass windows, stainless steel front, sides, top & back, vent riser, NSF, ETL, CE, ENERGY STAR®
Watch a video about this product
Blodgett CTB DBL Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Blodgett |
| Base | None |
| Controls | Manual |
| Depth (in) | 25.13 |
| Door Construction | Metal with Window |
| Door Type | Independent |
| Heat | Electric |
| Height (in) | 69.13 |
| Hertz | 60 |
| Interior Construction | Porcelain |
| kW | 5.6 |
| Number of Ovens | Double |
| Oven Interior Style | Standard Depth |
| Pans Per Deck | 5 |
| Phase | 1 |
| Product | Convection Ovens |
| Product Type | Cooking Equipment |
| Rating | Best |
| Series | CTB Series |
| Size | Half Size |
| Type | Floor Model |
| Voltage | 208 |
| Warranty | 3-year Parts; 2-year Labor; 5-year Door Parts |
| Width (in) | 30.25 |
| Weight | 595.00 |
