APW HFW-5D Drop-In Hot Food Well w/ (5) Full Size Pan Capacity, 208v/1ph

Image may not depict product color, inclusions or accessories.

KaTom #: 011-HFW5D • MPN: HFW-5D 208/240/60/1
Ships Free

Typically ships within 1 - 3 business days

Price Increase Warning
Retail Price: $2,648.00

Image may not depict product color, inclusions or accessories.

APW HFW-5D Description


With EZ locks on all sides, the APW Wyott HFW-5D drop-in hot food well can be installed in a wood or metal counter. The control box works best when front mounted, making it accessible to staff. Each of the five wells is controlled individually, with its own heat knob and pilot light. These wells accommodate full-size steam pans and can be used wet—with a shallow layer of water in the bottom—or dry without any liquid.

The wells are made of rust-resistant stainless steel on the inside and have drains to let out water at the end of the day. Removable mesh screens go over each drain opening, preventing food particles from clogging the pipes. S-shaped elements evenly heat the well bottoms and a layer of insulation under the wells retains heat, for energy efficiency. This APW Wyott HFW-5D drop-in well has securely fixed elements and aluminized housing to endure heavy use.

Product Details

  • (5) 12-in. x 20-in. heated wells
  • Each well can accommodate a full-size steam table pan
  • Stainless steel wells resist corrosion
  • Wells are individually controlled
  • Individual controls and pilot lights
  • Serpentine heating elements evenly warm the bottoms of wells
  • Aluminized housing reinforces elements
  • Insulation under the wells increases energy efficiency
  • 12-in. NPT drains for emptying each well
  • Removable drain screen for sifting out food debris
  • Durable aluminized housing
  • EZ locks on the sides expedite installation
  • Wet or dry operation
  • UL Sanitation and CSA listed; NSF certified

Dimensions & Utilities

  • Wells: 19.875 in. L x 11.875 in. W x 6.25 in. D
  • Recommended cutout: 71.747 in. L x 22.5 in. W
  • Overall: 72.875 in. L x 23.438 in. W x 8.639 in. H

For advice on choosing a drop-in well, read our drop-in food well article.

Hot Food Well Unit, drop-in, electric, (5) 12" x 20" wells, wet or dry operation, infinite controls, EZ lock, insulated, with drain, stainless steel wells, aluminized housing, cULus, CSA, NSF, CE, 208v/60/1ph

*The warranty will not be honored for residential or non-commercial use of any Commercial Equipment.

Warning Small Important Prop 65 information for California residents.

APW HFW-5D Specifications

PDF Spec Sheet
Manufacturer APW
Warranty 1 year limited parts & labor
Controls Infinite
Type Hot
Special Features Wet or Dry
Pan Size Full
Special Features With Drain
Phase 1
Voltage 208
Hertz 60
Product Hot Food Well
Product Type Food Bars & Buffets
Weight 118.00
APW HFW-5D Certifications
  • UL
  • NSF
