	TA Specification Series

TRUE FOOD SERVICE EQUIPMENT
True Heated Cabinets are designed to hold warm baked or cooked food. Cabinets are not designed to heat ambient or cold product.

Photo Includes Optional Accessories!

THIS PRODUCT TYPICALLY SHIPS IN 5 - 10 DAYS

Reach-In Solid Door Heated Cabinet
1 Door
31 Cubic Feet

MODEL TA2H2S

STANDARD FEATURES:

Powerfully provides holding temperatures of 80° F to 180° F throughout the cabinet for uniform, forced-air, heating.
Low velocity fan(s) provided to assure even temperature throughout cabinet. A vent is located at the top of the cabinet for positive humidity control.
Heater - stainless steel for corrosion resistance.
Shelving - (3) heavy duty, chrome shelves per section with wall mounted pilasters (shipped separately) (3) different interior kits available (field installation required).
Exterior - 300 series stainless steel front, sides, bottom and back (the finest stainless available).
Anodized aluminum interior.
Foamed-in-place polyurethane high density cell insulation (CFC free).
Exterior mounted, color coded, temperature monitor.
Lifetime guaranteed recessed door handles standard.
Door locks standard.
Doors equipped with lifetime guaranteed self-closing hinges with 120 degree stay open feature standard.
Humidity control - 12" x 20" pan standard.
Manual humidity control is a standard feature (turn counterclockwise to ventilate).
Incandescent interior lighting.
6" legs standard equipment. 4" diameter swivel castors available for single section models only.
Pass-thru heated cabinet designed to be rear-loaded from prep area and front accessed.
Self-contained system.

Features, Options & Specifications Subject to Change Without Notice.

OPTIONAL ACCESSORIES: Up-charge and lead times may apply.
4" (102 mm) diameter swivel castors. Seismic/flanged legs. Stainless steel (electro polished) shelves. All stainless steel legs. Chrome shelves. Universal pan slides. #1 pan slides. #2 rod style pan slides.	Curb mountable units. Export units - consult factory. Prison package options - consult factory. Metal door handle. Remote cabinets (condensing units supplied by others), consult factory technical service department for BTU information.

CLICK IMAGE FOR LARGER VIEW

SPECIFICATION IMAGES CURRENTLY UNAVAILABLE

ROUGH - IN DATA

This Product is recommended for commercial purposes only.

Specifications subject to change without notice
Chart dimensions rounded up to the nearest 1/8" .

Model	Doors	Capacity Cu. Ft.	Dimensions (Inches)			Watts	Volts	Amps	NEMA Config.	Cord Length (total feet)	Crated Weight
			L	D	H *
TA2H2S	2	56	51 3/8	34 3/4	78 1/4	4000	115/208-240/60 Hz,	N/A	N/A	N/A	565
* Height does not include 6" for leg height (castors available on single section models only). * Height does not include 1" for system mechanical components. Requires 115/208-240/60 Hz, single phase, 3 pole, 4 wire circuit. note: TA2H-2S requires hard wiring.

WARRANTY One year warranty on all parts & labor and an additional 4 year warranty on compressor. (U.S.A. only)	SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE		Model	Elevation	Right	Plan	3D
	SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE		TA2H2S	N/A	N/A	N/A	N/A
