Freezer Merchandiser, 1 Section/Glass Door, 3 Shelves, -10 F, 12 cu ft

MODEL GDM12F

• Oversized and balanced, environmentally friendly R404A refrigeration system holds -10° F.
• White laminated vinyl exterior.
• White, vinyl coated aluminum interior with 300 series stainless steel floor (NSF approved).
• Standard interior back guard and floor rack improve airflow (excludes GDM-5F-PT and GDM-7F).
• Fluorescent interior lighting.
• Integrated door light on GDM-23F and GDM-26F models.
• Adjustable vinyl coated wire shelves.
• Positive seal, torsion type closure system, self-closing doors.
• Extruded aluminum door frames.
• Energy efficient Low-E thermal glass doors.
• Epoxy coated evaporator.
• Large evaporator and coil heater permit short defrost cycle.
• Defrost system time initiated, temperature terminated.
• Automatic evaporator fan motor delay during defrost cycle.
• Bottom mount compressor.
• GDM-7F standard with 2 1/2 inch legs, leg levelers standard for all other models shown.
• 1 year parts & labor warranty (USA).
• 5 year compressor warranty (USA).

REFRIGERATION SYSTEM:

• Factory engineered self-contained, capillary tube system using environmentally friendly (CFC free) R404A refrigerant.

• Extra large evaporator coil balanced with higher horsepower compressor and large condenser; maintains -10° F (-23.3"C).

• Sealed, cast iron, self-lubricating evaporator fan motor and larger fan blades give True merchandisers a superior low velocity, high volume airflow design. This unique design insures colder standard temperatures and faster recovery in high use situations.

• Bottom mounted condensing unit positioned for easy maintenance. No stoop lower shelf maximizes visibility by raising merchandised product to  higher level.

• Defrost system time-initiated, temperature-terminated. Saves energy consumption and provides shortest possible defrost cycle.

CABINET CONSTRUCTION:

• Durable and permanent non-peel or chip white vinyl exterior standard. Black, rosewood and walnut available at no charge. Stainless steel available at an extra charge.

• White aluminum interior cabinet liner with 300 series stainless steel floor. Construction of liner in accordance with NSF standards.

• Safety shielded fluorescent interior lighting. Integrated door light standard on GDM-23F and GDM-26F.

• Interior rear wall airflow guard and floor rack prevent frozen product from blocking optimal airflow (excludes GDM-5F- PT, GDM-7F).

DOORS:

• Energy efficient Low-E thermal glass. Doors extend full width of cabinet shell. Door gaskets of one piece construction.

• Adjustable, self closing, torsion type closure system with aluminum block supports. The face of each door fitted with a 12" long handle.

• Extruded aluminum door frames

INSULATION:

• Entire cabinet structure insulated using foamed-in-place CFC free
  polyurethane foam.

SHELVING:

• Adjustable vinyl coated wire shelves included. Shelves capable of supporting up to 250 lbs.

• Full height shelf support pilasters, with double oblong holes on 1/2" centers. Pilasters made of the same material as cabinet interior. Four (4) chrome plated, stainless steel shelf clips to be included for each shelf.

ELECTRICAL CHARACTERISTICS:

• Unit completely pre-wired at factory, and ready for final connection to a 115/60/1 phase - 15 amp dedicated outlet.  A cord and plug set to be included.

• A sole use circuit is required.


OPTIONAL FEATURES / ACCESSORIES:
 (Up-charge and lead times may apply.)

• Novelty baskets (excludes GDM-5F-PT, -10F & 26F).

• Additional shelves.

• 2 1/2 inch castors for GDM-23F & -26F.

• Stainless steel or optional seismic legs for GDM-23F & GDM-26F.

• Remote cabinets and condensing units available for GDM-23F. Remote cabinets available for other models, consult factory.
