Hoshizaki DCM-270BAH-OS 288 lb Countertop Nugget Ice & Water Dispenser - 10 lb Storage, Cup Fill, 115v
Hoshizaki DCM-270BAH-OS Description
Great in lobbies, offices, hotels, or waiting rooms, the Hoshizaki DCM-270BAH-OS countertop ice and water dispenser is an ideal choice for places looking to provide ice or water to waiting customers. Under optimal conditions it produces 288 pounds of ice in a 24-hour span—more than enough to handle a standard customer flow. Increasing durability and protecting against rust, the dispenser has a stainless steel exterior and bin. To improve sanitation around the machine, its Opti-Serve LED sensors do the dispensing for the user, and with a self-contained design, this dispenser is protected from cross contamination.
Product Details
- 288-lb. maximum daily ice production
- 220-lb. AHRI-certified daily ice production
- Air-cooled system
- Dispenses cubelet (nugget) ice
- Cubelet ice size: 3⁄8 in. x 1⁄2 in. x 1⁄4-in. inner edge x 5⁄8-in. outer edge
- 10-lb. bin capacity
- LED housing is sealed to prevent moisture damage
- Self-contained design limits issues with cross contamination
- Hourly 2-sec. flush cycle keeps dispenser clean
- Resilient stainless steel exterior and bin are rust resistant
- H-GUARD Plus antimicrobial agent protects dispenser from contaminants
- Includes 4-in. legs
- Opti-Serve remote LED sensors enables hands-free ice dispensing
- Ideal ambient air temperature: 45-100 degrees F
- Ideal incoming water temperature: 45-90 degrees F
- Ideal incoming water pressure: 10-113 PSI
- Clearance requirements: 6 in. on left, 10 in. on right, 6 in. on rear, 20 in. on top
- R-404A refrigerant
- 3,532-BTU heat transfer capacity
Dimensions & Utilities
- 16 9⁄16 in. W x 24 1⁄8 in. D x 31 11⁄16 in. H
- 8.5 A, 7.3 kW
- 115 V/60 Hz/1 ph, 6-ft. cord with a NEMA 5-15P plug
Product Features

*Image may not depict product color, inclusions or accessories.
*Free shipping on Hoshizaki DCM-270BAH-OS within the 48 contiguous states.
From The Manufacturer
Opti-Serve Ice Maker/Water Dispenser, Cubelet-Style, air-cooled, self-contained condenser, production capacity up to 288 lb/24 hours at 70°/50° (220 lb AHRI certified at 90°/70°), 10 lb built-in storage capacity, counter model, LED sensor operation, stainless steel bin & exterior, protected with H-GUARD Plus Antimicrobial Agent, R-404A refrigerant, 4" legs, 115v/60/1-ph, 8.5 amps, NEMA 5-15P (optional stand sold separately), NSF, UL
Hoshizaki DCM-270BAH-OS Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| 24 Hr. Production (lb) | 282 |
| Amps | 8.5 |
| Bin Capacity (lb) | 10 |
| Compressor Type | Air Cooled |
| Depth (in) | 24.13 |
| Dispenser Type | Sensor |
| Dispenses | Ice & Water |
| Height (in) | 31.69 |
| Hertz | 60 |
| Ice Type | Nugget |
| Installation Type | Countertop |
| NEMA | 5-15P |
| Operation | Self Contained |
| Phase | 1 |
| Product | Ice Dispensers |
| Product Type | Ice Makers & Bins |
| Series | Opti-Serve |
| Serving Vessel | Cup |
| Special Features | CleanCycle24™ |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts |
| Width (in) | 16.56 |
| Weight | 170.00 |
Important Prop 65 information for California residents.
Compare to Similar Items
| Attributes |
Hoshizaki DCM-270BAH-OS Hoshizaki DCM-270BAH-OS 288 lb Countertop Nugget Ice & Water Dispenser - 10 lb Storage, Cup Fill, 115v Current Item |
|||
|---|---|---|---|---|
| Customer Rating |
|
|
|
|
| Price | $5,881.00 / Each | $5,672.00 / Each | $5,802.00 / Each | |
| Shipping | Free Shipping | Free Shipping | Free Shipping | Free Shipping |
| Lead Time | Typically ships in 4 - 8 Business Days | QUICK SHIP: Ships in 1 Business Day | QUICK SHIP: Ships in 1 Business Day | |
| Installation Type | Countertop | Countertop | Countertop | Countertop |
| Dispenses | Ice & Water | Ice & Water | Ice & Water | Ice & Water |
| Dispenser Type | Sensor | Sensor | Lever | Sensor |
| Bin Capacity (lb) | 10 | 12 | 10 | 10 |
| Ice Type | Nugget | Nugget | Nugget | Nugget |
| Serving Vessel | Cup | Cup | Cup | Cup |
| Series | Opti-Serve | Meridian™ | ||
| Operation | Self Contained | Self Contained | Self Contained | Self Contained |
| Special Features | CleanCycle24™ | H2 Harder Nugget Ice | Duratech™ | Duratech™ |
| Width (in) | 16.56 | 16.25 | 16.25 | 16.25 |
| 24 Hr. Production (lb) | 282 | 260 | 285 | 315 |
| Compressor Type | Air Cooled | Air Cooled | Air Cooled | Air Cooled |
| Warranty | 3-year Parts & Labor; 5-year Parts & Labor Evaporator; 5-year Compressor Parts | Commercial: 3-year Parts & Labor; 5-year Compressor & Condenser Parts; Residential: 1-year Parts & Labor | 2-year, 5-year Compressor Parts | 2-year, 5-year Compressor Parts |
