T&S B-1220 Pedestal Push Back Glass Filler, Double, Wall Mounted

KaTom #: 064-B1220 • MPN: B-1220
  • 064-B1220 Primary Thumbnail Image
Free Shipping Item

$215.05 /Each

Ship times may vary due to supply chain constraints. Please contact our Sales Team if you need this item in a specified time frame.

anthony schoggen User Image
Ask a Foodservice Equipment Specialist

T&S B-1220 Description

Equipped with a volume regulator and instantaneous shut-off, the T&S B-1220 pedestal push back glass filler offers measured dispensing for commercial drink stations. Its dark blue translucent Lexan push arm delivers water with a backward motion and can be fine-tuned using the included Torx wrench. The unit connects via a 3⁄8-inch NPT female inlet and delivers a flow rate of 1⁄4 GPM. Built of polished chrome-plated brass, the pedestal mounts to a deck using a 2-inch adjustable flange and stands 8 inches tall. This model is designed specifically for compatibility with electric water coolers.

Product Details

  • Deck-mount configuration
  • Polished chrome-plated brass body, pedestal, and flange
  • Dark blue translucent Lexan push-back arm with instantaneous shut-off
  • Volume regulator with Torx wrench-adjustable flow outlet (wrench included)
  • 8-in. height from base to outlet
  • 2-in. adjustable flange on pedestal
  • For mounting on electric water coolers
  • 3⁄8-in. NPT female inlet connection
  • 1⁄4 GPM
  • Operating pressure: 20-125 psi
  • Operating temperature: 40-140 degrees F (4 4⁄9 to 60 degrees C)

*Image may not depict product color, inclusions or accessories.

*Free shipping on T&S B-1220 within the 48 contiguous states.

Additional Product Information

Additional Product Information

From The Manufacturer

Glass Filler Faucet, pedestal push back, single, deck mounted, adjustable flange, volume regulator, blue lean arm, instant shut-off, 3/8" IPS female inlet, designed especially for mounting on electric water coolers

Warranty Icon
1-year Limited Against Defects in Material & Workmanship

T&S B-1220 Specifications
